Product Detailed Parameters
- Description：PIN HEADER, DOUBLE ROW, 10 PIN,
- Series：2215
- Mfr：Oupiin
- Package：Tape & Reel (TR)
- Connector Type：Header
- Contact Type：Male Pin
- Pitch - Mating：0.050" (1.27mm)
- Number of Positions：10
- Number of Rows：2
- Row Spacing - Mating：0.050" (1.27mm)
- Number of Positions Loaded：All
- Style：Board to Board
- Shrouding：Unshrouded
- Mounting Type：Surface Mount
- Termination：Solder
- Fastening Type：Push-Pull
- Contact Length - Mating：-
- Contact Length - Post：-
- Overall Contact Length：-
- Insulation Height：0.039" (1.00mm)
- Contact Shape：Square
- Contact Finish - Mating：Gold
- Contact Finish Thickness - Mating：Flash
- Contact Finish - Post：Gold
- Contact Material：Brass
- Insulation Material：Polyamide (PA6T), Nylon 6T
- Features：Board Guide, Pick and Place
- Operating Temperature：-40°C ~ 105°C
- Ingress Protection：-
- Material Flammability Rating：UL94 V-0
- Insulation Color：Black
- Current Rating (Amps)：1A
- Voltage Rating：-
Download product information
Overview
The Oupiin 2215-2X05G00DN-1.7T-H2.5-P is a board connector featuring 84 contacts arranged in two rows. It utilizes a male, straight receptacle design with a 0.05-inch pitch. The component measures 2.1 inches in length, 0.135 inches in width, and 0.045 inches in depth. Contacts are constructed from brass with round pin-skt styling and AU on NI mating finishes. Gold plating with a nickel barrier is applied to termination points. Electrical specifications include a contact resistance of 20 mΩ and an insulation resistance of 5,000,000,000 Ω.
Feature Summary
- Straight male receptacle configuration for direct board mounting
- Dual-row rectangular contact pattern ensuring high-density interconnects
- Gold-plated termination surfaces with nickel barriers for corrosion protection
Applications
- Computer system interconnections
- Telecommunications equipment signal routing
- Industrial production machinery control boards
- Electrical device interface modules
Procurement Notes
Verify the specific suffix codes against official manufacturer documentation to confirm exact physical dimensions and plating thickness. Ensure compatibility with mating header series within the 2215 family. Confirm RoHS compliance status through current datasheets before finalizing procurement orders.
Selection Notes
Select this component when a straight, dual-row male connector is required for high-density applications. Consider the 0.05-inch pitch constraint and the specific housing dimensions during PCB layout. Verify that the brass contact material and gold finish meet the environmental and electrical requirements of the target circuit.
Part Context
This part belongs to the Oupiin 2215 series of board connectors. The series is characterized by automated manufacturing processes and strict quality control systems. Products in this line are widely utilized across global computer, communication, and industrial sectors, adhering to ISO9001 standards and various safety certifications.
Replacement Considerations
Consult official cross-reference lists for compatible alternatives within the same pitch and contact count range. Verify mechanical fit and electrical ratings before substituting with other manufacturers' products.
