22286283 is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Molex. Its product description is CONN HEADER R/A 28POS 2.54MM. Review the specifications below when checking this part for your BOM.
Headers, Male Pins specifications for 22286283
- Description：CONN HEADER R/A 28POS 2.54MM
- Series：KK254, 42376
- Mfr：Molex
- Package：Bulk
- Connector Type：Header, Breakaway
- Contact Type：Male Pin
- Pitch - Mating：0.100" (2.54mm)
- Number of Positions：28
- Number of Rows：1
- Row Spacing - Mating：-
- Number of Positions Loaded：All
- Style：Board to Board or Cable
- Shrouding：Unshrouded
- Mounting Type：Through Hole, Right Angle
- Termination：Solder
- Fastening Type：Push-Pull
- Contact Length - Mating：0.405" (10.29mm)
- Contact Length - Post：0.120" (3.05mm)
- Overall Contact Length：-
- Insulation Height：0.090" (2.29mm)
- Contact Shape：Square
- Contact Finish - Mating：Gold
- Contact Finish Thickness - Mating：15.0µin (0.38µm)
- Contact Finish - Post：Tin
- Contact Material：-
- Insulation Material：Polyamide (PA), Nylon, Glass Filled
- Features：-
- Operating Temperature：-
- Ingress Protection：-
- Material Flammability Rating：UL94 V-0
- Insulation Color：Black
- Current Rating (Amps)：-
- Voltage Rating：-
Headers, Male Pins datasheet and documents for 22286283
Headers, Male Pins Overview
The Molex part number 22286283 is identified as a component within the 207121 series, classified under HANDTOOL Series extraction tools. It is specifically designed for use with connector systems requiring terminal removal or insertion operations. The tool features a tip width of 2.36 mm, engineered to interface with specific contact geometries found in Molex connector assemblies. This component serves as a specialized instrument for maintenance and assembly tasks involving electrical interconnects.
Headers, Male Pins Feature Summary
- Designed for precise terminal extraction and insertion operations
- Compatible with specific connector contact geometries
- Part of the standardized HANDTOOL Series for consistent performance
Headers, Male Pins Applications
- Connector maintenance and repair
- Terminal replacement in assembled harnesses
- Quality assurance testing of connector contacts
Headers, Male Pins Procurement Notes
Verify the exact specification against official Molex documentation before procurement. Confirm compatibility with the target connector series, as generic tool descriptions may not account for subtle design variations between different connector families. Ensure the tool matches the required tip dimensions for the specific application.
Headers, Male Pins Selection Notes
Select this tool based on its specific tip width of 2.36 mm and its designation within the HANDTOOL Series. Ensure it aligns with the connector system's mechanical requirements. Cross-reference the part number with official Molex catalogs to confirm its intended use case and avoid selecting incompatible variants.
Headers, Male Pins Part Context
This component belongs to the 207121 series, which encompasses various hand tools for connector servicing. It is distinct from other series like Mini-Lock or Perma-Seal, which utilize different tooling standards. The HANDTOOL Series provides a range of specialized instruments for diverse connector types.
Headers, Male Pins Replacement Considerations
Public confirmed substitute part numbers are not available in the provided data. Consult official Molex resources for potential alternatives if this specific part number is discontinued or unavailable.
