2241-C1X06G00DBU

$0.41

Description：PIN HEADER, TYPE C, SINGLE ROW,
Series：2241
Mfr：Oupiin
Package：Tube

SKU:2a95d6f4bd7c Category: Headers, Male Pins Brand: Oupiin

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：PIN HEADER, TYPE C, SINGLE ROW,
Series：2241
Mfr：Oupiin
Package：Tube
Connector Type：Header
Contact Type：Male Pin
Pitch - Mating：-
Number of Positions：6
Number of Rows：1
Row Spacing - Mating：-
Number of Positions Loaded：All
Style：Board to Board
Shrouding：-
Mounting Type：Surface Mount
Termination：Solder
Fastening Type：Push-Pull
Contact Length - Mating：-
Contact Length - Post：-
Overall Contact Length：-
Insulation Height：-
Contact Shape：Square
Contact Finish - Mating：Gold
Contact Finish Thickness - Mating：Flash
Contact Finish - Post：Gold
Contact Material：-
Insulation Material：-
Features：-
Operating Temperature：-
Ingress Protection：-
Material Flammability Rating：-
Insulation Color：-
Current Rating (Amps)：-
Voltage Rating：-

Download product information

2241-C1X06G00DBU

Overview

The Oupiin 2241-C1X06G00DBU is a surface mount board connector featuring six contacts arranged in a single row. Designed as a male header with pin-style terminals, it utilizes a solder termination method for secure PCB attachment. The component incorporates a low-profile housing construction to minimize vertical space requirements within electronic assemblies.

Feature Summary

Surface mount configuration for automated assembly processes
Low profile design suitable for compact system integration

Applications

General electronic circuit interconnections
Compact device signal routing

Procurement Notes

Verify the specific manufacturer datasheet for the 2241-C1X06G00DBU to confirm exact mechanical dimensions and material specifications. Ensure compatibility with standard surface mount reflow profiles. Cross-reference official documentation to validate terminal plating and insulation ratings before finalizing procurement decisions.

Selection Notes

Select this component when a low-profile, six-position male header is required for surface mount applications. Evaluate spatial constraints against the specified height parameters. Confirm that the solder termination type aligns with the intended manufacturing process and PCB layout requirements.

Part Context

This part belongs to the Oupiin 2241 series of rectangular connectors. The series typically includes various contact counts and mounting styles. This specific model represents a surface mount variant designed for reliable electrical connections in modern electronics manufacturing environments.

Replacement Considerations

Consult official distributor databases for confirmed substitute part numbers from Oupiin or compatible manufacturers. Verify mechanical footprint and electrical characteristics before substitution.
