2242-2X34C00DU

Overview

The Oupiin 2242-2X34C00DU is a PCB socket connector featuring a double row configuration with 68 positions. It utilizes a 0.050-inch (1.27mm) pitch and employs surface mount technology for board attachment. The contacts are gold-plated to ensure reliable electrical performance. This component is RoHS compliant and lead-free, meeting environmental standards for modern electronics manufacturing.

Feature Summary

• Double row receptacle design for high-density interconnects
• Surface mount terminal style for automated assembly
• Gold contact plating for corrosion resistance

Applications

• General purpose PCB interconnection
• Industrial control systems
• Consumer electronic devices

Procurement Notes

Verify the specific manufacturer datasheet for detailed mechanical dimensions and mating force specifications. Confirm that the selected variant matches the required surface mount footprint and pin count. Ensure compliance with local environmental regulations regarding RoHS and lead-free content before finalizing procurement orders.

Selection Notes

Select this component when a double-row, surface-mount female socket is required for 68-position connections. The 0.050-inch pitch is standard for many through-hole and SMT applications. Consider the gold plating for durability in environments requiring frequent mating cycles or exposure to corrosive elements.

Part Context

This part belongs to Oupiin's series of headers and receptacles designed for board-to-board or cable-to-board connections. The 2242 series typically offers robust mechanical stability and consistent electrical characteristics suitable for mass production environments in the electronics industry.

Replacement Considerations

Direct substitutes must match the 68-pin, double-row, 0.050-inch pitch, and surface mount form factor. Verify compatibility with existing PCB footprints and mating header specifications before replacing.
