2246-1X25G00SU

Overview

The Oupiin 2246-1X25G00SU is a single-row PCB socket connector featuring 25 positions with a 0.050-inch (1.27mm) pitch. Designed for through-hole mounting, it utilizes gold-plated contacts to ensure reliable signal transmission and low contact resistance. The component is RoHS compliant and lead-free, adhering to environmental standards. It serves as a female receptacle intended for mating with corresponding male headers in electronic assemblies.

Feature Summary

• Single-row configuration for compact board layout
• Gold-plated contacts for enhanced conductivity
• Through-hole termination method for secure attachment

Applications

• General-purpose electronic circuit boards
• Industrial control systems
• Consumer electronics assemblies

Procurement Notes

Verify the specific pin count and pitch against design requirements before ordering. Confirm that the supplier provides official datasheets to validate RoHS compliance and material specifications. Ensure the selected variant matches the required surface finish and mounting style for the target application.

Selection Notes

Select this component when a single-row, 25-position female socket is required. The 1.27mm pitch suits standard density applications. Consider the through-hole mounting requirement and gold plating needs for corrosion resistance and contact reliability during the selection process.

Part Context

This part belongs to the Oupiin 2246 series of headers and receptacles. The series offers various position counts and row configurations. The 2246-1X25G00SU specifically addresses the need for a 25-contact female interface in single-row arrangements.

Replacement Considerations

Compatible substitutes include other 25-position, 1.27mm pitch single-row sockets from different manufacturers, provided mechanical dimensions and electrical ratings match. Verify pin compatibility and mounting hole alignment before substitution.
