2248-A2X30G00DNU-M

Overview

The Oupiin 2248-A2X30G00DNU-M is a rectangular PCB socket connector designed for surface mount applications. It features a double row configuration with 60 pins, providing a total contact count suitable for high-density interconnects. The component utilizes a 1.27mm (0.050 inch) row spacing to accommodate precise board layouts. Termination is achieved through soldering, ensuring secure attachment to the printed circuit board. The fastening mechanism employs a push-pull system, facilitating efficient mating and unmating processes during assembly or maintenance.

Feature Summary

• Double row construction for increased pin density within a compact footprint
• Push-pull fastening type to ensure reliable connection retention
• Surface mount termination method for automated PCB assembly compatibility

Applications

• High-density electronic board interconnections
• Server and storage backplane systems
• Industrial control modules requiring robust signal paths

Procurement Notes

Verify the specific ordering suffix against the manufacturer's current datasheet to confirm exact pin count and contact finish specifications. Ensure that the selected variant matches the required row spacing and mounting style for your design. Cross-reference the part number with official Oupiin documentation to validate availability and technical compliance before finalizing procurement orders.

Selection Notes

Select this component when a 60-pin double row interface is required with 1.27mm pitch. The push-pull latching mechanism is essential for applications needing secure mechanical retention without screws. Confirm that the surface mount package aligns with the PCB fabrication capabilities and thermal requirements of the target assembly process.

Part Context

This model belongs to Oupiin's series of high-reliability rectangular connectors. These components are engineered for demanding environments where stable electrical performance and mechanical durability are critical. The product line emphasizes precision manufacturing to support complex electronic architectures in modern hardware systems.

Replacement Considerations

Direct substitutes must match the 60-pin count, 1.27mm pitch, double row layout, and push-pull fastening mechanism. Verify that any alternative component maintains identical surface mount termination and housing dimensions to ensure mechanical fit and electrical continuity in existing designs.
