2328461-2

$17.71

Description：CONN EDGE DUAL FML 280POS 0.024
Series：Sliver 2.0
Mfr：TE Connectivity AMP Connectors
Package：Tray

SKU:60be03e6eaff Category: Edgeboard Connectors Brand: TE Connectivity AMP Connectors

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

2328461-2 is listed in the Edgeboard Connectors range at ChipApex. The manufacturer field lists TE Connectivity AMP Connectors. Its product description is CONN EDGE DUAL FML 280POS 0.024. Review the specifications below when checking this part for your BOM.

Edgeboard Connectors specifications for 2328461-2

Description：CONN EDGE DUAL FML 280POS 0.024
Series：Sliver 2.0
Mfr：TE Connectivity AMP Connectors
Package：Tray
Card Type：Non Specified - Dual Edge
Gender：Female
Number of Positions/Bay/Row：28; 28; 28; 28; 28
Number of Positions：280
Card Thickness：0.062" (1.57mm)
Number of Rows：2
Pitch：0.024" (0.60mm)
Read Out：Dual
Features：Board Guide, Pick and Place, Solder Retention
Mounting Type：Surface Mount
Termination：Solder
Contact Material：Copper Alloy
Contact Finish：Gold
Contact Finish Thickness：15.0µin (0.38µm)
Contact Type：-
Color：Black
Flange Feature：-
Operating Temperature：-55°C ~ 85°C

Edgeboard Connectors datasheet and documents for 2328461-2

2328461-2

Edgeboard Connectors Overview

The TE Connectivity AMP Connectors part number 2328461-2 is a standard card edge connector assembly designed for surface mount applications. It features a dual-edge configuration with 280 positions and a contact pitch of 0.024 inches (0.60mm). The contacts are constructed from copper alloy with a gold finish, providing reliable electrical performance. The housing is black, and the component utilizes solder termination for secure PCB attachment.

Edgeboard Connectors Feature Summary

Dual-edge card edge design for high-density signal transmission
Gold-plated copper alloy contacts for corrosion resistance
Surface mount termination method for automated assembly

Edgeboard Connectors Applications

High-speed data interface modules
Industrial control system backplanes
Telecommunications equipment interconnects

Edgeboard Connectors Procurement Notes

Verify the specific suffix codes against official TE Connectivity documentation to ensure compatibility with required mating connectors and PCB stack-up dimensions. Confirm that the gold finish thickness meets the intended application's wear requirements. Cross-reference the 280-position count with schematic designs to prevent pinout mismatches during integration.

Edgeboard Connectors Selection Notes

Select this component when a high-pin-count, dual-edge solution is required for space-constrained surface mount designs. Ensure the PCB layout supports the 0.60mm pitch and that the mating connector aligns with the dual-edge geometry. Consider thermal management capabilities during peak operation loads.

Edgeboard Connectors Part Context

This assembly belongs to the standard card edge connector family from TE Connectivity, widely used in modular electronic systems. It complements single-edge variants by offering double-sided contact access, effectively doubling the I/O capacity within the same footprint constraints compared to older generation connectors.
