Edgeboard Connectors Overview

The TE Connectivity AMP Connectors part number 2332139-6 is a dual-edge card edge connector receptacle assembly belonging to the Sliver 2.0 series. It features 140 positions arranged in two rows of 70 contacts each, with a pitch of 0.024 inches (0.60mm). Designed for surface mount installation, the connector utilizes gold-plated copper alloy contacts and a black liquid crystal polymer (LCP) insulator. The unit supports board thicknesses up to 0.062 inches (1.57mm) and operates within a temperature range of -55°C to 85°C.

Edgeboard Connectors Feature Summary

• Dual-edge configuration accommodates double-sided circuit boards
• Gold-plated contacts ensure reliable signal transmission
• Surface mount design facilitates automated pick-and-place assembly

Edgeboard Connectors Applications

• High-density electronic interconnects
• Telecommunications equipment
• Industrial control systems

Edgeboard Connectors Procurement Notes

Verify the exact manufacturer part number against official TE Connectivity documentation before ordering. Confirm that the specific suffix matches the required contact plating and packaging format. Ensure compatibility with standard surface mount reflow profiles and check for any RoHS compliance requirements relevant to your region.

Edgeboard Connectors Selection Notes

Select this component when high pin counts are required in a compact footprint. The 0.60mm pitch allows for dense routing on small boards. Verify that the target PCB thickness falls within the supported range and that the mating card edge material is compatible with the contact design.

Edgeboard Connectors Part Context

This connector is part of the Sliver 2.0 family, engineered for applications demanding high reliability in space-constrained environments. The series is known for its robust mechanical retention and consistent electrical performance under thermal cycling conditions typical in modern electronics manufacturing.

Edgeboard Connectors Replacement Considerations

Consult TE Connectivity official substitution guides for verified alternatives. Generic equivalents may not match the precise dimensional tolerances or contact plating specifications required for dual-edge interfaces.
