2340-6111TB

Headers, Male Pins Overview

The 3M 2340-6111TB is a vertical PCB header connector featuring 40 positions with a 2.54mm pin spacing. It is designed for through-hole mounting and provides reliable electrical interconnection in electronic assemblies.

Headers, Male Pins Feature Summary

• Vertical orientation for standard PCB mounting
• 40-position configuration for multi-signal routing
• 2.54mm pitch ensures compatibility with standard components

Headers, Male Pins Applications

• General electronic circuit boards
• Industrial control systems
• Consumer electronics assemblies

Headers, Male Pins Procurement Notes

Verify the specific manufacturer part number against official 3M Electronic Solutions Division documentation to confirm exact pin count, pitch, and termination style. Ensure the vertical header specification matches the target PCB layout requirements before finalizing procurement decisions.

Headers, Male Pins Selection Notes

Select this component when a 40-pin vertical interface is required on a printed circuit board. The 2.54mm spacing is standard for general-purpose electronics, ensuring broad compatibility with mating connectors and assembly tools.

Headers, Male Pins Part Context

This connector belongs to the 3M headers and wire housings category, specifically within the rectangular connector family. It serves as a fixed interface point for signal transmission in various electronic hardware designs.

Headers, Male Pins Replacement Considerations

Consult official 3M cross-reference guides for verified substitute part numbers. Do not assume generic equivalents match the specific mechanical or electrical tolerances of this 40-position header.
