2345808-3

Edgeboard Connectors Overview

The TE Connectivity AMP Connectors part number 2345808-3 is a standard edge connector assembly designed for board-to-board applications. It features a dual-sided configuration with 28 positions arranged in two rows. The connector utilizes a 0.6 mm pitch and employs right-angle mounting to facilitate compact circuit board layouts. Contact surfaces are gold-plated copper alloy, ensuring reliable signal transmission. The housing is constructed from liquid crystal polymer (LCP) material. The component supports a maximum operating temperature of +85°C and carries an ampacity rating of 1.1 A.

Edgeboard Connectors Feature Summary

• Dual-sided receptacle assembly design for vertical board insertion
• Gold-plated contacts on copper alloy substrate for corrosion resistance
• Right-angle orientation for space-constrained PCB integration
• Liquid crystal polymer housing for thermal stability

Edgeboard Connectors Applications

• High-density electronic module interconnection
• Telecommunications equipment backplanes
• Industrial control system boards
• Consumer electronics internal connectivity

Edgeboard Connectors Procurement Notes

Verify the specific suffix codes against official TE Connectivity documentation to confirm exact plating thickness and housing color variations. Ensure compatibility with mating card edge thickness specifications before procurement. Confirm RoHS compliance status through current manufacturer declarations as regulatory requirements may evolve. Cross-reference the Mouser catalog number 571-2345808-3 for accurate distributor identification and availability checks.

Edgeboard Connectors Selection Notes

Select this component when a low-profile, high-pin-count edge connector is required for right-angle PCB mounting. The 0.6 mm pitch allows for dense I/O configurations within limited board areas. Verify that the application environment remains within the +85°C maximum operating temperature limit. Ensure the mating card edge meets the mechanical tolerances specified for the 28-position dual-row interface to guarantee proper contact engagement.

Edgeboard Connectors Part Context

This component belongs to the Standard Edge Connector family manufactured by TE Connectivity / AMP. It serves as a receptacle assembly intended to mate with corresponding card edge connectors. The product line focuses on providing reliable electrical connections in compact form factors suitable for modern electronic assemblies requiring high pin counts in small footprints.

Edgeboard Connectors Replacement Considerations

No public confirmed substitute part numbers are available in the provided source data. Consult TE Connectivity engineering support for cross-referencing compatible alternatives based on specific mechanical and electrical requirements.
