Edgeboard Connectors Overview

The TE Connectivity AMP Connectors part number 2345808-4 is a 28-position female connector belonging to the Sliver 2.0 series. It features a dual-edge configuration with a 0.60mm (0.024 inch) pitch. The component utilizes gold flash contact finish over a copper alloy base material. Designed for surface mount applications, it offers right-angle termination via soldering. The housing is constructed from black liquid crystal polymer (LCP).

Edgeboard Connectors Feature Summary

• Dual-edge female connector design for board-to-board interconnection.
• Surface mount right-angle termination compatible with automated assembly.
• Gold flash contact finish ensures reliable signal transmission and corrosion resistance.

Edgeboard Connectors Applications

• High-density electronic assemblies requiring compact footprint.
• Consumer electronics utilizing surface mount technology.
• Industrial control modules needing reliable right-angle connections.

Edgeboard Connectors Procurement Notes

Verify the specific suffix and revision level against the manufacturer's latest datasheet before ordering. Confirm that the surface mount package dimensions align precisely with the target PCB layout. Ensure compatibility with standard reflow soldering profiles for gold-plated contacts. Check for any recent product change notices affecting materials or manufacturing locations.

Edgeboard Connectors Selection Notes

Select this component when a low-profile, high-pin-count solution is required in a limited vertical space. The dual-edge design allows for increased I/O density compared to single-edge alternatives. Consider the right-angle orientation for efficient cable routing or board stacking constraints. Validate thermal performance requirements against the LCP housing specifications.

Edgeboard Connectors Part Context

This connector belongs to the Sliver 2.0 family, characterized by fine pitch and miniaturization. It serves as a specialized interconnect solution within TE Connectivity's broader portfolio of high-reliability connectors. The series targets applications demanding robust performance in compact form factors.

Edgeboard Connectors Replacement Considerations

Consult official substitution guides for direct pin-compatible alternatives. Verify mechanical fit and electrical characteristics before adopting substitute part numbers.
