Edgeboard Connectors Overview

The TE Connectivity AMP Connectors part number 2345808-6 is a rectangular cable assembly classified as a standard card edge connector. It features a 28-position receptacle assembly with a right-angle mounting style. The connector utilizes a 0.6 mm pitch and employs gold-plated contacts made from copper alloy. The housing is constructed from liquid crystal polymer (LCP) in a silver finish. It supports a maximum operating temperature of +85°C and has a current rating of 1.1 A.

Edgeboard Connectors Feature Summary

• Right-angle receptacle assembly design for board edge insertion
• Gold-plated copper alloy contacts ensuring reliable signal transmission
• Liquid crystal polymer housing material for thermal stability

Edgeboard Connectors Applications

• Electronic circuit board interconnections
• Industrial control systems requiring right-angle mounting
• Consumer electronics hardware assemblies

Edgeboard Connectors Procurement Notes

Verify the specific ordering suffix and RoHS compliance status directly against the manufacturer's official datasheet before procurement. Confirm that the right-angle configuration and 28-position count match the target application requirements. Ensure the supplier provides valid traceability documentation to guarantee component authenticity and quality standards are met.

Edgeboard Connectors Selection Notes

Select this component when a right-angle, 28-position card edge interface is required. The 0.6 mm pitch dictates compatible mating dimensions. Verify that the system environment remains within the +85°C maximum operating temperature limit. Ensure the mechanical fit allows for the specified right-angle orientation without interference.

Edgeboard Connectors Part Context

This component belongs to the standard card edge connector category manufactured by TE Connectivity AMP Connectors. It serves as a female receptacle designed for vertical or right-angle PCB integration. The product line focuses on providing robust electrical connections for multi-pin applications in compact electronic devices.

Edgeboard Connectors Replacement Considerations

The model 2345808-2 is a documented substitute within the same series. Both share identical specifications including the 28-position count, right-angle orientation, and 0.6 mm pitch. Verify compatibility before substitution.
