23S180C

Fixed Inductors Overview

The 23S180C is a shielded surface-mount power inductor from the Murata 2300 series, designed for PCB mounting. It features a bobbin core construction and offers an inductance of 18 uH with a maximum DC current rating of 450 mA. The component exhibits a maximum DC resistance of 641 mOhms and operates within a temperature range of -40 C to +85 C. Its physical dimensions are 6.2 mm in length, 5.6 mm in width, and 3.2 mm in height, supporting standard SMD/SMT termination types.

Fixed Inductors Feature Summary

• Shielded design to minimize electromagnetic interference
• Bobbin wound core structure for stable performance
• Surface-mount package optimized for automated assembly

Fixed Inductors Applications

• General power supply circuits
• DC-DC converter modules
• Signal filtering applications

Fixed Inductors Procurement Notes

Verify the manufacturer part number against official Murata Power Solutions documentation to ensure authenticity. Confirm that the received components match the specified electrical parameters, including inductance and current ratings. Check for compliance with RoHS standards as indicated in the product specifications. Ensure storage conditions maintain component integrity prior to installation.

Fixed Inductors Selection Notes

Select this component when a compact, shielded inductor is required for space-constrained designs. The 18 uH value and 450 mA current rating suit moderate power applications. Consider the low profile height for boards with strict thickness limitations. Verify thermal management requirements against the specified operating temperature range.

Fixed Inductors Part Context

This component belongs to the 2300 series of fixed inductors manufactured by Murata Power Solutions. It is categorized under power inductors with surface-mount technology. The series utilizes bobbin-wound construction techniques to achieve specific magnetic properties suitable for electronic power processing tasks.

Fixed Inductors Replacement Considerations

Consult official Murata Power Solutions substitution guides for verified equivalent parts. Cross-reference specifications such as inductance, current rating, and physical dimensions before implementing any alternative components.
