Product Detailed Parameters
- Description：LINE FLTR 1000VDC 150A CHASS MNT
- Series：EVX
- Mfr：TE Connectivity Corcom Filters
- Package：Box
- Filter Type：DC
- Configuration：Two Stage
- Voltage - Rated DC：1000V (1kV)
- Voltage - Rated AC：-
- Current：150 A
- Frequency - Operating：DC
- Applications：Converter
- Approval Agency：UR
- Operating Temperature：-40°C ~ 100°C
- Mounting Type：Chassis Mount
- Termination Style：Terminal Post
- Inductance：-
- Voltage - Rated AC (Phase to Ground/Neutral)：-
- Voltage - Rated AC (Phase to Phase)：-
Download product information
Overview
The TE Connectivity Corcom Filters model 2443554-2 is a DC EMC/EMI line filter belonging to the EVX series. It features a two-stage terminal post design and is rated for 1000V (1kV) DC with a maximum current capacity of 150 A. The component utilizes busbar termination types for both input and output connections, ensuring robust electrical interfacing for high-power applications.
Feature Summary
- Two-stage filtering architecture for enhanced noise suppression
- High voltage DC capability up to 1000V
- Busbar termination style for secure high-current connections
Applications
- Electric vehicle fast charging systems
- Industrial power converters
- High-power DC distribution networks
Procurement Notes
Verify the specific current rating requirements against the 150 A specification before procurement. Confirm that the busbar termination type matches the existing chassis mounting infrastructure. Ensure the 1000V DC rating aligns with the system's operational voltage limits to prevent insulation failure or safety hazards during installation.
Selection Notes
Select this component when high-voltage DC filtering is required in compact spaces. The two-stage design offers superior attenuation compared to single-stage alternatives. Consider the physical dimensions and busbar interface compatibility with the target enclosure. This model is suitable for environments demanding reliable EMI/EMC performance under heavy load conditions.
Part Context
This part belongs to the Corcom EVX series, which specializes in high-voltage DC filters for demanding industrial and automotive applications. The series is engineered to handle significant power levels, supporting systems ranging from tens of kilowatts to megawatts. It complements other EVX models by providing specialized configurations for different current and voltage ratings within the same product family.
Replacement Considerations
Publicly confirmed substitute part numbers are not available in the provided documentation. Verify compatibility with direct replacements by matching the 1000V DC rating, 150 A current capacity, and busbar termination style.
