Overview

The TE Connectivity Corcom Filters model 2443554-3 is a two-stage DC EMC/EMI line filter from the EVX series. It features a terminal post termination style and is rated for 1000V DC with a current capacity of 150A. The component is RoHS compliant and designed for high-voltage direct current applications.

Feature Summary

• Two-stage filtering architecture
• High voltage DC rating
• Terminal post termination

Applications

• Electric vehicle charging systems
• High voltage DC power distribution
• Industrial DC power supplies

Procurement Notes

Verify the specific current and voltage ratings against the official datasheet before integration, as high-power DC filters require precise matching to system load profiles. Confirm that the terminal post interface aligns with existing busbar or cable assembly specifications to ensure mechanical stability and electrical continuity in high-current environments.

Selection Notes

Select this component when a robust two-stage attenuation solution is required for 1000V DC circuits carrying up to 150A. Ensure the application environment supports the thermal characteristics of chassis-mounted EMI filters and that the terminal post connection method is compatible with the available wiring infrastructure.

Part Context

This part belongs to the Corcom EVX series, which specializes in high-voltage DC filtering solutions. The series is engineered for demanding power electronics applications where significant electromagnetic interference suppression is critical for maintaining signal integrity and regulatory compliance in DC power lines.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation.
