2450FM07A0035001T

Overview

The Johanson Technology 2450FM07A0035001T is a surface-mount low-pass RF filter designed for the 2.45 GHz frequency band. It features a 100 MHz bandwidth and an insertion loss of 0.75 dB. The component utilizes a 0402 (1005 metric) package with four PCB pads, measuring 1.00 mm in length, 0.50 mm in width, and a maximum height of 0.40 mm. It operates within a temperature range of -40°C to +85°C and complies with RoHS3 standards.

Feature Summary

• Provides signal filtering for 2.45 GHz applications using a low-pass design
• Utilizes a compact 0402 surface-mount ceramic package
• Ensures reliable operation across industrial temperature ranges

Applications

• Wireless LAN (WLAN) systems
• Bluetooth Low Energy (BLE) devices
• Zigbee communication modules

Procurement Notes

Verify the complete part number including the trailing 'T' to confirm tape-and-reel packaging. Confirm the 0402 footprint dimensions match the target PCB layout. Ensure the 0.75 dB insertion loss specification meets system link budget requirements. Check RoHS3 compliance status if required by specific regional regulations.

Selection Notes

Select this component when space constraints require a 0402 form factor for 2.4 GHz filtering. Consider the 0.75 dB insertion loss impact on overall system gain. Evaluate the 100 MHz bandwidth against adjacent channel interference needs. Verify thermal stability requirements align with the -40°C to +85°C operating range.

Part Context

This component belongs to Johanson Technology's RF filter portfolio, specifically engineered for ISM band applications. It serves as a passive signal conditioning element within wireless transceiver front-ends. The product line supports miniaturization trends in IoT and mobile connectivity hardware.

Replacement Considerations

No public substitute part numbers are documented for this specific model.
