2499-003-X5W0-502PLF

Overview

The 2499-003-X5W0-502PLF is an EMI feedthrough filter manufactured by Tusonix, a subsidiary of CTS Electronic Components. This component functions as a feed-through capacitor with a capacitance value of 5000 pF and a tolerance range of 0% to +100%. It features a rated voltage of 500Vdc at 85°C and supports a current rating of 20 A. The device utilizes an axial bushing package configuration. Its operating temperature range spans from -55°C to 85°C. Designed for EMI/RFI suppression, it serves as a critical element in filtering applications requiring high voltage and current handling capabilities within specified thermal limits.

Feature Summary

• Provides effective EMI and RFI suppression through feed-through capacitor technology
• Supports high current loads up to 20 A with robust voltage ratings
• Utilizes axial bushing package for secure mounting and connection

Applications

• EMI/RFI suppression in electronic systems
• High-voltage power line filtering
• Industrial equipment noise reduction

Procurement Notes

Verify the specific manufacturer part number against official Tusonix or CTS documentation to ensure authenticity. Confirm that the axial bushing package and electrical ratings match your system requirements. Check for any updated compliance certifications or datasheet revisions before finalizing procurement decisions to avoid compatibility issues.

Selection Notes

Select this component when EMI/RFI suppression is required alongside high voltage and current handling. Ensure the 500Vdc rating and 20A current capacity align with circuit demands. Verify that the axial bushing form factor fits the mechanical constraints of the installation environment. Consider the operating temperature range for thermal management planning.

Part Context

This component belongs to the Tusonix family of EMI feedthrough filters, designed for robust noise suppression. As a subsidiary of CTS Electronic Components, Tusonix specializes in high-reliability filtering solutions. The 2499 series typically offers various capacitance and voltage options to suit diverse industrial and commercial applications requiring effective electromagnetic interference mitigation.

Replacement Considerations

Consult official Tusonix or CTS documentation for confirmed substitute part numbers. Do not assume cross-compatibility with other manufacturers' components without verifying electrical and mechanical specifications.
