Product Detailed Parameters
- Description：LINE FLTR 520VAC 250A CHASS MNT
- Series：KEV
- Mfr：TE Connectivity Corcom Filters
- Package：Box
- Filter Type：Three Phase (Wye)
- Configuration：Two Stage
- Voltage - Rated DC：-
- Voltage - Rated AC：520V
- Current：250 A
- Frequency - Operating：50/60Hz
- Applications：General Purpose
- Approval Agency：CSA, UL
- Operating Temperature：-25°C ~ 85°C
- Mounting Type：Chassis Mount
- Termination Style：Threaded Post (M10)
- Inductance：-
- Voltage - Rated AC (Phase to Ground/Neutral)：-
- Voltage - Rated AC (Phase to Phase)：-
Download product information
Overview
The TE Connectivity Corcom Filters 250KEVD10BFPW is a three-phase (wye) EMC/EMI line filter designed for high-current industrial applications. It supports a rated current of 250 A and operates at voltages up to 520 VAC with a frequency range of 50/60 Hz. The unit features a dual-stage configuration utilizing threaded post terminals (M10) for secure connection. Designed for flange mounting, it provides robust electromagnetic interference suppression in demanding power distribution environments.
Feature Summary
- Dual-stage EMI/EMC filtering architecture for enhanced noise attenuation
- High-capacity 250 A current handling capability for heavy-duty loads
- Threaded post terminal interface ensuring reliable mechanical and electrical connections
Applications
- Industrial power distribution systems requiring high current filtration
- Three-phase motor drive installations
- Heavy machinery power supply units
Procurement Notes
Verify the specific voltage rating requirement against the 520 VAC specification before procurement. Confirm that the M10 threaded post terminal style matches the existing busbar or cable lug design. Ensure the flange mounting dimensions are compatible with the intended chassis or panel cutout to avoid installation issues.
Selection Notes
Select this component when a three-phase wye configuration is required for currents exceeding standard single-phase limits. The dual-stage design offers superior performance compared to single-stage alternatives. Consider the physical size constraints associated with flange-mounted high-current filters during the initial system layout phase.
Part Context
This part belongs to the KEV series from TE Connectivity's Corcom Filters division, which specializes in high-performance power line filters. The KEV series is engineered for rigorous industrial environments, offering reliable EMI suppression for sensitive electronic equipment connected to noisy power grids.
Replacement Considerations
Public confirmed substitute part numbers are not available in the provided documentation. Verify compatibility with existing mounting hardware and terminal configurations if considering alternative manufacturers.
