25KEBS6AFPD

Overview

The 25KEBS6AFPD is a three-phase superior performance EMI power line filter manufactured by TE Connectivity Corcom Filters. It features a chassis mount installation style with screw termination and is rated for 440 VAC at 250 A. The unit operates within a temperature range of -25°C to +85°C and has dimensions of 373 mm in length, 220 mm in width, and 91 mm in height.

Feature Summary

• Provides superior performance EMI/RFI filtering for three-phase power lines
• Designed for high-current industrial applications up to 250 A
• Utilizes a robust chassis mount configuration with screw terminals

Applications

• Industrial machinery power conditioning
• Three-phase motor drive systems
• Heavy-duty manufacturing equipment

Procurement Notes

Verify current availability status as the component may be subject to obsolescence or limited supply constraints. Confirm that the required mounting hardware and terminal specifications align with existing chassis designs. Ensure compliance with local safety certifications such as UL and CSA before integration into final assemblies.

Selection Notes

Select this model when high current capacity and superior noise attenuation are required for three-phase systems. Compare against lower-rated series if current demands exceed 250 A. Verify that the physical dimensions fit within the designated enclosure space and that the operating temperature range meets environmental requirements.

Part Context

This component belongs to the KEB series of power line filters from TE Connectivity Corcom Filters. The series is engineered for demanding industrial environments requiring reliable electromagnetic interference suppression. It serves as a critical interface between the power source and sensitive electronic loads.

Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided documentation. Consult manufacturer resources for potential cross-references or updated product line replacements.
