Product Detailed Parameters
- Description：LINE FILTER 520VAC 20A CHASS MNT
- Series：KEB
- Mfr：TE Connectivity Corcom Filters
- Package：Bulk,Box
- Filter Type：Three Phase (Delta)
- Configuration：Single Stage
- Voltage - Rated DC：-
- Voltage - Rated AC：520V
- Current：20 A
- Frequency - Operating：50/60Hz
- Applications：General Purpose
- Approval Agency：CSA, UL
- Operating Temperature：-25°C ~ 85°C
- Mounting Type：Chassis Mount
- Termination Style：Threaded Post (M5)
- Inductance：-
- Voltage - Rated AC (Phase to Ground/Neutral)：-
- Voltage - Rated AC (Phase to Phase)：-
Download product information
Overview
The TE Connectivity Corcom Filters model 25KEBS6BFPD is a single-stage, three-phase power line filter designed for chassis mounting. It features a threaded bolt flange mount configuration and utilizes nut termination for secure electrical connections. The component is rated for a current of 25A at a voltage of 520VAC with a frequency of 50Hz. This EMI/RFI filter is engineered to suppress electromagnetic interference in industrial power distribution systems.
Feature Summary
- Provides single-stage EMI/RFI filtering for three-phase AC power lines
- Features a robust chassis mount design with threaded bolt flange installation
- Utilizes nut-style termination for reliable high-current connectivity
Applications
- Industrial machinery power input stages
- Three-phase motor drive systems
- Commercial power distribution units requiring EMI suppression
Procurement Notes
Verify the specific voltage rating of 520VAC and current capacity of 25A against your system requirements before procurement. Confirm that the chassis mounting hole pattern and threaded bolt specifications match your enclosure design. Ensure the nut termination style is compatible with your wiring harness or busbar connection method to guarantee proper mechanical and electrical integration.
Selection Notes
Select this component when a single-stage filtering solution is sufficient for your EMI reduction needs in three-phase applications. Consider the 520VAC rating and 25A current capacity to ensure compatibility with your power source. The chassis mount form factor requires adequate panel space and access for the threaded bolt installation. Evaluate if the nut termination style aligns with your assembly process compared to screw or quick-connect alternatives.
Part Context
This part belongs to the TE Connectivity Corcom Filters series, specifically within their power line filter portfolio. The Corcom brand is recognized for providing comprehensive EMI/RFI filtering solutions for various industrial and commercial applications. This specific model represents a standard offering for three-phase power conditioning and noise suppression tasks.
Replacement Considerations
Public confirmed substitute part numbers are not available in the provided documentation. Verify compatibility with existing designs by matching electrical ratings and mechanical dimensions before considering alternative components.
