2744065446

Overview

The Fair-Rite 2744065446 is a surface-mount common mode choke designed for signal line filtering and electromagnetic interference suppression. It features a two-line configuration with an impedance of 255 ohms at 100 MHz. The component utilizes ferrite material and operates within a temperature range of -55 °C to 125 °C. It complies with RoHS standards and is housed in an EIA standard 0805 package size.

Feature Summary

• Two-line common mode choke configuration for effective noise reduction
• Surface mount design suitable for automated assembly processes
• Ferrite construction optimized for high-frequency signal integrity

Applications

• Signal line filtering
• Electromagnetic interference suppression
• Common-mode noise reduction on data lines

Procurement Notes

Verify the specific manufacturer part number 2744065446 against official Fair-Rite documentation to confirm current lifecycle status and technical specifications. Ensure compatibility with required impedance values and package dimensions before integration into designs.

Selection Notes

Select this component when a compact, surface-mount solution is required for suppressing common-mode noise on signal lines. The 0805 footprint and 255-ohm impedance at 100 MHz make it suitable for high-speed digital interfaces where space constraints are critical.

Part Context

This component belongs to the Fair-Rite common mode choke product family, specifically engineered for surface-mount applications. It addresses the need for compact EMI suppression in modern electronic devices where traditional through-hole components are impractical due to size limitations.

Replacement Considerations

Consult Fair-Rite datasheets for direct equivalents or alternative series parts with matching impedance curves and package dimensions. Verify that any substitute maintains the same thermal performance and RoHS compliance requirements.
