2823382-7

Headers, Male Pins Overview

The TE Connectivity AMP Connectors part number 2823382-7 is a connector header designed for through-hole mounting. It features a single row with seven positions and a pitch of 0.079 inches (2.00mm). The contacts are made from phosphor bronze, ensuring reliable conductivity. The housing is constructed from thermoplastic material, providing structural integrity. This component is intended for board-to-board or cable-to-board interconnection applications requiring secure mechanical attachment via the through-hole termination method.

Headers, Male Pins Feature Summary

• Through-hole termination method ensures robust mechanical fixation to printed circuit boards.
• Single-row configuration provides compact layout efficiency for multi-pin connections.
• Phosphor bronze contact material offers durable electrical performance.

Headers, Male Pins Applications

• Board-to-board interconnections
• Cable-to-board assemblies
• General electronic equipment wiring

Headers, Male Pins Procurement Notes

Verify the specific pin count and pitch against design requirements before ordering. Confirm that the through-hole footprint matches the target PCB layout. Ensure compatibility with standard wave soldering or manual soldering processes used in the manufacturing line. Check for any specific handling instructions regarding the thermoplastic housing material.

Headers, Male Pins Selection Notes

Select this component when a low-profile, single-row header is required for through-hole assembly. Consider the 2.00mm pitch for spacing constraints. Evaluate the phosphor bronze contacts for current carrying needs. Compare against surface mount alternatives if space limitations differ. Verify housing material compatibility with operating temperatures.

Headers, Male Pins Part Context

This part belongs to the broader category of interconnect devices manufactured by TE Connectivity AMP Connectors. It serves as a fundamental passive component in electronic assemblies, facilitating signal and power transmission between circuit boards or cables. Its design prioritizes mechanical stability and electrical reliability in standard industrial environments.

Headers, Male Pins Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Cross-reference with other manufacturers' headers only if exact dimensional and electrical specifications can be independently verified against official datasheets.
