2867001502

Overview

Fair-Rite part number 2867001502 is a multi-aperture ferrite core constructed from Material 67. It features five circular apertures, each with an internal diameter of approximately 3.8 mm. The component measures 13.3 mm in external length and is designed for board-level suppression applications. Material 67 provides high permeability suitable for low-frequency noise attenuation.

Feature Summary

• Multi-aperture design accommodating multiple conductors simultaneously
• Material 67 composition optimized for low-frequency magnetic performance
• Solid construction without split halves or gaps

Applications

• Board component EMI suppression
• Printer friendly data sheet integration
• Multi-conductor cable filtering

Procurement Notes

Verify the specific material grade and aperture count against the manufacturer datasheet before procurement. Confirm that the 3.8 mm aperture diameter accommodates the target conductor bundle size. Ensure the board component application aligns with the physical dimensions and mounting requirements of the design.

Selection Notes

Select this component when simultaneous suppression of multiple lines is required on a single substrate. Material 67 is appropriate for applications prioritizing low-frequency permeability over high-frequency impedance magnitude. Compare the five-aperture configuration against single-hole alternatives to determine space efficiency needs.

Part Context

This part belongs to Fair-Rite's multi-aperture ferrite core series. It differs from standard toroids by providing multiple independent paths for signal lines within a single magnetic structure. The use of Material 67 distinguishes it from higher-frequency materials like 43 or 61.

Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation.
