28S2011-0M0

Overview

The 28S2011-0M0 is a clip-style ferrite core manufactured by Laird-Signal Integrity Products, designed for electromagnetic interference suppression on cables and wiring. It utilizes Material 28 to provide an impedance of 280 Ohms at 100 MHz. The component features a flat clip design that requires two units to form one assembly. Its physical dimensions include an outer size of 3.000 inches in width by 0.250 inches in height (76.20mm x 6.35mm) and an inner dimension of 2.570 inches in width by 0.033 inches in height (65.28mm x 0.84mm).

Feature Summary

• Clip-together design requiring two pieces per assembly for secure cable retention.
• High impedance performance of 280 Ohms at 100 MHz using Material 28.

Applications

• Electromagnetic interference filtering for cables and wiring harnesses.
• Signal integrity protection in electronic assemblies.

Procurement Notes

Verify the specific part number suffix to confirm the clip configuration and material grade. Ensure procurement quantities account for the requirement of two units per single assembled core. Confirm RoHS compliance status with the supplier prior to ordering.

Selection Notes

Select this component when high impedance at 100 MHz is required for cable shielding. The clip design allows for easy installation on existing cables without soldering. Verify that the cable diameter fits within the specified inner dimensions of 65.28mm width and 0.84mm height.

Part Context

This ferrite core belongs to the standard cable core product line from Laird-Signal Integrity Products. It is categorized under passive components and filters, specifically designed for EMI suppression applications in various electronic environments.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. Consult manufacturer catalogs for equivalent Material 28 clip cores with matching impedance and dimensional specifications.
