2EZP

Description：LINE FILTER 250VAC 2A TH
Series：Z
Mfr：TE Connectivity Corcom Filters
Package：Bulk

SKU:31f3679640cc Category: Power Line Filter Modules Brand: TE Connectivity Corcom Filters

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：LINE FILTER 250VAC 2A TH
Series：Z
Mfr：TE Connectivity Corcom Filters
Package：Bulk
Filter Type：Single Phase
Configuration：Single Stage
Voltage - Rated DC：-
Voltage - Rated AC：250V
Current：2:00 AM
Frequency - Operating：50/60Hz
Applications：General Purpose
Approval Agency：CSA, UR, VDE
Operating Temperature：-10°C ~ 40°C
Mounting Type：Through Hole
Termination Style：PC Pins
Inductance：21.52mH

Download product information

2EZP

Overview

The TE Connectivity Corcom Filters 2EZP is a single-phase EMI/RFI power line filter designed for printed circuit board (PCB) mounting. It features a rated AC voltage of 250VAC and a current rating of 2A, operating at frequencies of 50/60Hz. The component utilizes wire lead termination for integration into electronic assemblies. It is RoHS compliant and certified by CSA, UR, and VDE agencies.

Feature Summary

Provides electromagnetic interference and radio frequency interference filtering for commercial applications
Designed for direct printed circuit board installation using wire leads
Certified for international safety standards including CSA, UR, and VDE

Applications

Commercial electronic equipment requiring EMI suppression
General-purpose AC power line filtering
Printed circuit board assembly integration

Procurement Notes

Verify the specific datasheet version (1.2EZP.pdf or 2.2EZP.pdf) to confirm exact physical dimensions and pin configurations before finalizing design integration. Confirm that the RoHS3 compliance status aligns with current regulatory requirements for the target market, as environmental classifications can vary by manufacturing batch and region.

Selection Notes

Select this component when a compact, PCB-mount solution is required for low-current AC applications up to 2A. Ensure the available wire lead length accommodates the board layout constraints. Verify that the single-stage filtering performance meets the specific noise attenuation requirements of the sensitive electronics in the system.

Part Context

This part belongs to the Corcom Filters series manufactured by TE Connectivity. It is categorized under power line filters intended for general commercial use. The product is distinct from chassis-mounted or panel-mount variants within the same family, offering a specialized form factor for internal board-level integration rather than external enclosure mounting.
