3-1609090-9

Overview

The TE Connectivity Corcom Filters 3-1609090-9 is a single-phase EMC/EMI power line filter designed for industrial applications. It supports a rated current of 16 A at 250 VAC and operates within the 50/60 Hz frequency range. The component features a single-stage configuration with quick connect terminals and an M8 threaded post interface. Certified by UL, CSA, and VDE, it provides essential noise suppression for sensitive electronic equipment in standard electrical environments.

Feature Summary

• Provides effective electromagnetic interference and radio frequency interference suppression
• Utilizes a robust mechanical design with threaded post mounting for secure installation
• Ensures compliance with international safety standards for global deployment

Applications

• Industrial control panels requiring EMI protection
• Medical equipment power inputs
• Automated machinery signal integrity maintenance

Procurement Notes

Verify the specific terminal type and mounting requirements against the official datasheet before ordering. Confirm that the M8 threaded post interface matches the chassis design. Ensure the 16 A current rating aligns with the system's maximum load to prevent thermal issues. Check for any recent product change notices regarding manufacturing locations or material composition updates.

Selection Notes

Select this model when a single-phase solution is required for high-current applications up to 16 A. The M8 threaded post offers a secure connection method suitable for vibration-prone environments. Consider the single-stage filtering capability as sufficient for moderate noise attenuation needs. Evaluate the physical dimensions to ensure compatibility with the available panel space.

Part Context

This component belongs to the TE Connectivity Corcom Filters series, known for reliable power line conditioning. The 3-1609090-9 designation identifies a specific variant within the broader portfolio of EMI filters. It serves as a critical interface between the power source and sensitive loads, ensuring clean power delivery in demanding operational settings.

Replacement Considerations

Consult the official TE Connectivity selector guide for direct equivalents. Verify that any substitute maintains the 16 A rating and M8 mounting specification. Cross-reference certification requirements to ensure regulatory compliance remains intact.
