302-R201

Headers, Male Pins Overview

The 302-R201 is a male pin header connector manufactured by On Shore Technology Inc. It features a right-angle through-hole mounting style with 20 positions and a 0.100 inch (2.54mm) pitch. The contacts are gold-plated brass pins designed for board-to-cable or wire applications. Rated at 3A current and 250V voltage, it utilizes a shrouded four-wall design to ensure proper alignment and protection during mating.

Headers, Male Pins Feature Summary

• Right-angle configuration for space-efficient PCB layout
• Shrouded four-wall housing prevents misalignment
• Gold-plated contacts ensure reliable conductivity
• Through-hole termination for secure mechanical attachment

Headers, Male Pins Applications

• Board-to-cable interconnections
• Wire-to-board connections
• General electronic assembly requiring right-angle headers

Headers, Male Pins Procurement Notes

Verify the specific pin count and pitch against the target PCB footprint before ordering. Confirm that the shrouded design aligns with the mating connector requirements. Ensure the operating temperature range meets the application environment standards. Check RoHS compliance if required by project specifications.

Headers, Male Pins Selection Notes

Select this component when a right-angle male header is required for 2.54mm pitch applications. The 20-position count suits moderate density connections. Consider the 3A rating for signal or low-power distribution. The shrouded design is critical where orientation accuracy is paramount.

Headers, Male Pins Part Context

This part belongs to the 302 series of rectangular connectors from On Shore Technology Inc. The series offers various position counts and configurations. The 302-R201 specifically addresses the need for right-angle mounting in compact assemblies while maintaining standard 2.54mm spacing compatibility.

Headers, Male Pins Replacement Considerations

Compatible substitutes must match the 20-position count, 2.54mm pitch, right-angle orientation, and shrouded four-wall design. Verify that alternative manufacturers offer equivalent gold plating thickness and current ratings to ensure functional interchangeability.
