302-R261

Headers, Male Pins Overview

The 302-R261 is a male pin header manufactured by On Shore Technology Inc. It features a right-angle configuration with 26 positions and a 2.54mm pitch. Designed for through-hole mounting, this connector utilizes gold-plated contacts to ensure reliable signal transmission in electronic assemblies.

Headers, Male Pins Feature Summary

• Right-angle orientation facilitates compact board layout
• Gold-plated contact surfaces enhance conductivity
• Through-hole termination method ensures mechanical stability

Headers, Male Pins Applications

• General-purpose electronic circuit interconnections
• Industrial control system module connections
• Consumer electronics internal wiring

Headers, Male Pins Procurement Notes

Verify the specific manufacturer datasheet for precise mechanical dimensions and plating thickness specifications. Confirm that the right-angle form factor aligns with the target PCB assembly constraints before finalizing component selection.

Headers, Male Pins Selection Notes

Select this component when a rigid, right-angle connection is required for 26-position signals. Ensure the 2.54mm spacing matches the existing footprint design and verify that the through-hole process capability supports the selected package type.

Headers, Male Pins Part Context

This part belongs to the standard header series from On Shore Technology Inc., focusing on reliable vertical or angled interconnect solutions. The 26-position count provides a balanced density for multi-signal routing without excessive board space consumption.

Headers, Male Pins Replacement Considerations

Compatible alternatives include the 302-S261 variant, which offers a vertical configuration instead of right-angle. Both share the same 26-position count and 2.54mm pitch, allowing for potential mechanical adaptation if board orientation permits.
