302-R301

Headers, Male Pins Overview

The 302-R301 is a right-angle male header connector manufactured by On Shore Technology Inc. It features a 30-position configuration with a 2.54mm (0.100 inch) pitch, designed for through-hole termination. The contacts are gold-plated to ensure reliable signal transmission and corrosion resistance. Rated for 3A current and 250V voltage, the component operates within a temperature range of -40°C to 105°C. The housing is black, providing visual contrast and insulation integrity.

Headers, Male Pins Feature Summary

• Right-angle design facilitates compact board layout and perpendicular connection orientation
• Gold-plated contact finish ensures durable electrical performance and oxidation resistance
• Shrouded box header structure provides alignment stability and pin protection during mating

Headers, Male Pins Applications

• Industrial control system interconnections
• Consumer electronics internal circuit boards
• Communication equipment signal routing

Headers, Male Pins Procurement Notes

Verify that the ordered part number matches the specific suffix requirements for contact plating and housing color. Confirm that the supplier provides original manufacturer documentation or authorized distributor certificates to guarantee authenticity. Ensure storage conditions prevent moisture absorption prior to soldering, as improper handling may affect solder joint reliability and long-term performance in harsh environments.

Headers, Male Pins Selection Notes

Select this component when a right-angle male header with 30 positions and 2.54mm pitch is required. Ensure the PCB footprint matches the through-hole specification and verify that the 3A current rating per contact meets the circuit load requirements. Consider the operating temperature range and shrouded design for applications requiring precise alignment and environmental protection.

Headers, Male Pins Part Context

This component belongs to the 302-R series of interconnect headers from On Shore Technology Inc., which offers various position counts and configurations. The series is characterized by shrouded box designs and right-angle orientations, suitable for dense electronic assemblies where space efficiency and secure mating are critical for maintaining signal integrity across multiple connections.

Headers, Male Pins Replacement Considerations

Direct substitutes must match the 30-position count, 2.54mm pitch, right-angle orientation, and through-hole termination method. Verify compatibility with existing PCB footprints and housing dimensions. Contact finish and current ratings should be equal or superior to ensure equivalent performance without redesigning the assembly.
