302-R341

Headers, Male Pins Overview

The 302-R341 is a shrouded box header connector manufactured by On Shore Technology Inc. It features a right-angle male pin configuration with 34 positions arranged in a single row. The connector utilizes a 0.100-inch (2.54mm) pitch and is designed for through-hole mounting on printed circuit boards. Electrical specifications include a current rating of 3A and an operating temperature range from -40°C to 105°C. The contacts are constructed from brass with gold plating to ensure reliable signal transmission.

Headers, Male Pins Feature Summary

• Right-angle design facilitates compact board layout integration
• Shrouded box header structure provides alignment and protection
• Gold-plated brass contacts ensure durable electrical connectivity

Headers, Male Pins Applications

• General-purpose electronic circuit interconnections
• Industrial control system board-to-board connections
• Consumer electronics assembly requiring right-angle headers

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix against official manufacturer documentation to confirm contact plating thickness and material composition. Ensure the selected variant matches the required 34-position count and right-angle orientation. Cross-reference the datasheet for precise mechanical dimensions and thermal ratings before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a high-density, right-angle interconnection solution is required for PCB assemblies. The 2.54mm pitch is standard for general electronics, while the shrouded design aids in mating accuracy. Consider the 3A current rating and 105°C temperature limit to ensure compatibility with the target application's electrical and thermal environment.

Headers, Male Pins Part Context

This part belongs to the 302-R series of interconnect headers from On Shore Technology Inc. The series offers various position counts and configurations, providing flexibility for different board space constraints. As a right-angle header, it is distinct from straight-through variants, optimizing vertical clearance in enclosed equipment designs.

Headers, Male Pins Replacement Considerations

Direct substitutes must match the 34-position count, 2.54mm pitch, right-angle orientation, and shrouded box style. Verify that alternative manufacturers offer compatible through-hole termination and similar electrical ratings to ensure functional interchangeability without mechanical modification.
