302-S301

Headers, Male Pins Overview

The On Shore Technology Inc. 302-S301 is a vertical shrouded header connector designed for through-hole mounting on printed circuit boards. It features a 30-position configuration with male pin contacts arranged in a single row. The connector utilizes a 2.54mm pitch to ensure precise alignment and reliable signal transmission. Constructed with brass contacts, it supports a current rating of 3A. The unit measures 45.7mm in length, 9.1mm in depth, and 9.1mm in height, operating at temperatures up to 105°C.

Headers, Male Pins Feature Summary

• Shrouded design provides four-sided guidance to prevent misalignment during mating
• Vertical orientation facilitates direct board-to-board or cable-to-board connections
• Through-hole solder termination ensures secure mechanical attachment to the PCB

Headers, Male Pins Applications

• Industrial control system interconnections
• Consumer electronics assembly
• General-purpose circuit board linking

Headers, Male Pins Procurement Notes

Verify that the specific part number matches the required 30-position count and 2.54mm pitch before ordering. Confirm that the through-hole mounting style aligns with your PCB fabrication capabilities. Ensure the operating temperature range of 105°C meets your environmental requirements. Cross-reference the manufacturer's latest documentation to confirm availability and any potential obsolescence notices prior to finalizing procurement decisions.

Headers, Male Pins Selection Notes

Choose this component when a shrouded header is necessary to guide mating connectors and prevent pin damage. The 3A current rating suits low-power signal and power distribution tasks. Consider the vertical profile and through-hole requirement against available board space and assembly methods. Compare alternative positions within the 302-S series if different contact counts are needed for the same form factor.

Headers, Male Pins Part Context

This component belongs to the 302-S series of shrouded box headers manufactured by On Shore Technology Inc. The series offers various position counts, including 24, 26, 34, 40, 50, 60, and 64 positions, sharing similar physical dimensions and mounting characteristics. The 302-S301 specifically fills the gap for applications requiring exactly thirty connection points within this standardized vertical header family.

Headers, Male Pins Replacement Considerations

Direct substitutes within the same series include the 302-S241, 302-S261, 302-S341, 302-S401, 302-S501, 302-S601, and 302-S641. These parts share identical mounting styles and pitch but differ in contact quantity. Verify that the alternative position count fits the design constraints before swapping.
