302-S341

Headers, Male Pins Overview

The On Shore Technology Inc. 302-S341 is a shrouded header connector designed for through-hole PCB mounting. It features a vertical orientation with 34 positions arranged in a single row. The pitch between contacts is 2.54mm (0.100 inches). The connector utilizes gold-plated contacts to ensure reliable signal transmission and corrosion resistance. It is rated for a maximum voltage of 250V and a current capacity of 3A. The housing is constructed from black insulating material compliant with UL94 V-0 flammability standards. A keying slot is integrated into the design to prevent incorrect mating.

Headers, Male Pins Feature Summary

• Shrouded four-sided header design for secure alignment
• Vertical through-hole termination for standard PCB assembly
• Gold contact finish for enhanced conductivity
• Integrated keying slot to prevent misalignment

Headers, Male Pins Applications

• Industrial control panel interconnections
• Consumer electronics board-to-board connections
• General-purpose circuit board signal routing

Headers, Male Pins Procurement Notes

Verify that the required pin count matches exactly thirty-four positions. Confirm the vertical mounting style aligns with the mechanical constraints of the target enclosure. Ensure the operating environment does not exceed the specified 250V voltage rating or 3A current limit. Check for compatibility with mating sockets regarding the keying slot configuration.

Headers, Male Pins Selection Notes

Select this component when a high-density, vertically oriented connection is required for through-hole applications. The 2.54mm pitch offers a balance between spacing density and ease of manual handling. The shrouded design provides superior protection against accidental short circuits compared to open headers. Consider the UL94 V-0 rating if fire safety compliance is critical for the application.

Headers, Male Pins Part Context

This part belongs to the 302 series of rectangular connectors manufactured by On Shore Technology Inc. The series typically includes various pin counts and configurations to support diverse electronic assembly needs. The 302-S341 specifically addresses requirements for higher channel counts while maintaining standard industry spacing dimensions.

Headers, Male Pins Replacement Considerations

Direct substitutes must match the 34-position count, 2.54mm pitch, and vertical through-hole form factor. Verify that alternative manufacturers offer compatible shrouding and keying specifications to ensure mechanical interchangeability without modifying the PCB layout.
