305-080-521-201 is listed in the Edgeboard Connectors range at ChipApex. The manufacturer field lists EDAC Inc.. Its product description is CONN EDGE DUAL FMALE 80POS 0.156. Review the specifications below when checking this part for your BOM.
Edgeboard Connectors specifications for 305-080-521-201
- Description：CONN EDGE DUAL FMALE 80POS 0.156
- Series：305
- Mfr：EDAC Inc.
- Package：Box
- Card Type：Non Specified - Dual Edge
- Gender：Female
- Number of Positions/Bay/Row：40
- Number of Positions：80
- Card Thickness：0.054" ~ 0.070" (1.37mm ~ 1.78mm)
- Number of Rows：2
- Pitch：0.156" (3.96mm)
- Read Out：Dual
- Features：-
- Mounting Type：Through Hole
- Termination：Solder
- Contact Material：Copper Alloy
- Contact Finish：Gold
- Contact Finish Thickness：10.0µin (0.25µm)
- Contact Type：Semi Bellows
- Color：Green
- Flange Feature：-
- Operating Temperature：-40°C ~ 105°C
Edgeboard Connectors datasheet and documents for 305-080-521-201
Edgeboard Connectors Overview
The EDAC Inc. 305-080-521-201 is a standard card edge connector receptacle featuring 80 positions in a dual configuration. It utilizes a 0.156-inch (3.96 mm) contact spacing with gold-plated copper alloy contacts and a green thermoplastic polyester insulator. Designed for panel mount installation, this component supports solder termination and accommodates printed circuit boards with a nominal thickness of 0.062 inches (1.57 mm).
Edgeboard Connectors Feature Summary
- Dual-edge female contact configuration for secure board insertion.
- Gold-plated contacts ensure reliable electrical conductivity.
- Low-profile insulator body design for space-constrained applications.
Edgeboard Connectors Applications
- Industrial control systems requiring robust interconnects.
- Medical equipment needing reliable signal transmission.
- Automotive technology interfaces demanding durability.
Edgeboard Connectors Procurement Notes
Verify the complete part number including suffixes to confirm specific plating thickness and housing color variations. Confirm RoHS compliance status and mating board thickness requirements against the official datasheet before procurement to ensure mechanical compatibility.
Edgeboard Connectors Selection Notes
Select this model when a high-density 80-position interface is required with a 3.96 mm pitch. Ensure the application environment falls within the specified operating temperature range and that the PCB thickness matches the connector's acceptance criteria for proper retention.
Edgeboard Connectors Part Context
This component belongs to the EDAC 305 Series, a line of standard card edge connectors designed for general-purpose interconnect solutions. The series offers various position counts and configurations to support diverse electronic assembly needs across multiple industries.
Edgeboard Connectors Replacement Considerations
Compatible substitutes include other EDAC 305-series variants with matching 80-position dual-edge specifications. Verify identical pin count, pitch, and mounting style before substitution.
