305-086-521-278

$13.85

Description：CONN EDGE DUAL FMALE 86POS 0.156
Series：305
Mfr：EDAC Inc.
Package：Box

SKU:ee6c84477568 Category: Edgeboard Connectors Brand: EDAC Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

305-086-521-278 is listed in the Edgeboard Connectors range at ChipApex. The manufacturer field lists EDAC Inc.. Its product description is CONN EDGE DUAL FMALE 86POS 0.156. Review the specifications below when checking this part for your BOM.

Edgeboard Connectors specifications for 305-086-521-278

Description：CONN EDGE DUAL FMALE 86POS 0.156
Series：305
Mfr：EDAC Inc.
Package：Box
Card Type：Non Specified - Dual Edge
Gender：Female
Number of Positions/Bay/Row：43
Number of Positions：86
Card Thickness：0.054" ~ 0.070" (1.37mm ~ 1.78mm)
Number of Rows：2
Pitch：0.156" (3.96mm)
Read Out：Dual
Features：-
Mounting Type：Panel Mount, Through Hole
Termination：Solder
Contact Material：Copper Alloy
Contact Finish：Gold
Contact Finish Thickness：10.0µin (0.25µm)
Contact Type：Semi Bellows
Color：Green
Flange Feature：Flush Mount, Top Opening, Threaded Insert, 4-40
Operating Temperature：-40°C ~ 105°C

Edgeboard Connectors datasheet and documents for 305-086-521-278

305-086-521-278

Edgeboard Connectors Overview

The EDAC Inc. 305-086-521-278 is a standard card edge connector from the 305 series, designed for panel mount applications with a vertical orientation. It features 86 positions in a dual row configuration with a contact spacing of 3.96 mm (0.156 inches). The connector utilizes gold-plated copper alloy contacts and solder pin termination. It accepts printed circuit boards with a nominal thickness of 1.57 mm (0.062 inches) and offers a continuous current rating of 5 A.

Edgeboard Connectors Feature Summary

Accepts between-contact and in-contact polarizing keys for secure board alignment
Features a low profile insulator body constructed from thermoplastic polyester
Provides high dielectric strength with a 1800 VACrms insulation voltage rating

Edgeboard Connectors Applications

Computing and storage system interconnects
Medical device hardware connections
Aerospace and industrial control panels
Communications network infrastructure

Edgeboard Connectors Procurement Notes

Verify the specific ordering suffix to confirm the exact contact plating thickness and insulator color variant, as these attributes may vary within the 305 series product line. Ensure that the selected polarizing key type matches the mechanical requirements of the target printed circuit board design before finalizing procurement orders.

Edgeboard Connectors Selection Notes

Select this component when a dual-row connection with a 3.96 mm pitch is required for thick PCBs up to 1.57 mm. The 5 A current rating supports moderate power distribution needs. Consider the vertical panel mount style for rigid structural integration where space constraints favor a low-profile insulator body design.

Edgeboard Connectors Part Context

This part belongs to the EDAC 305 series, which specializes in card edge connectors for rack and panel applications. The series is characterized by robust construction suitable for demanding environments. EDAC provides extensive design and manufacturing support for these interconnect solutions across global distribution channels.
