306-006-400-101 is listed in the Edgeboard Connectors range at ChipApex. The manufacturer field lists EDAC Inc.. Its product description is CONN EDGE DUAL FMALE 12POS 0.156. Review the specifications below when checking this part for your BOM.
Edgeboard Connectors specifications for 306-006-400-101
- Description：CONN EDGE DUAL FMALE 12POS 0.156
- Series：306
- Mfr：EDAC Inc.
- Package：Bulk
- Card Type：Non Specified - Dual Edge
- Gender：Female
- Number of Positions/Bay/Row：6
- Number of Positions：12
- Card Thickness：0.054" ~ 0.070" (1.37mm ~ 1.78mm)
- Number of Rows：2
- Pitch：0.156" (3.96mm)
- Read Out：Dual
- Features：-
- Mounting Type：Free Hanging (In-Line)
- Termination：Solder Eyelet(s)
- Contact Material：Copper Alloy
- Contact Finish：Tin
- Contact Finish Thickness：-
- Contact Type：Cantilever
- Color：Green
- Flange Feature：-
- Operating Temperature：-40°C ~ 105°C
Edgeboard Connectors datasheet and documents for 306-006-400-101
Edgeboard Connectors Overview
The EDAC Inc. 306-006-400-101 is a standard card edge connector receptacle featuring 12 positions with a 0.156-inch (3.96 mm) contact spacing. Designed for dual-edge board insertion, it utilizes tin-plated copper alloy contacts and a green thermoplastic polyester insulator. The component supports panel mount installation in a vertical orientation with solder pin termination. It accommodates PCB thicknesses within specified mechanical limits and operates reliably across a temperature range of -55°C to +125°C.
Edgeboard Connectors Feature Summary
- Dual-edge female configuration for secure single-sided or double-sided card engagement
- Vertical panel mount design with solder pin termination for stable circuit integration
- Thermoplastic polyester insulator providing robust environmental resistance
Edgeboard Connectors Applications
- Industrial control system interconnects
- Telecommunications equipment backplanes
- Consumer electronics modular assemblies
Edgeboard Connectors Procurement Notes
Verify the specific ordering suffix against official EDAC documentation to confirm plating type and flange configuration. Ensure the target application requires the 12-position variant with 0.156-inch spacing. Confirm RoHS compliance status matches project requirements before finalizing procurement orders.
Edgeboard Connectors Selection Notes
Select this component when a dual-edge receptacle with 12 positions and 3.96 mm pitch is required. Verify that the mating card thickness falls within the connector's mechanical acceptance range. Ensure the vertical panel mount style aligns with the enclosure design constraints.
Edgeboard Connectors Part Context
This part belongs to the EDAC 306 Series, which provides standard card edge connectors for general-purpose applications. The series offers various position counts and termination options to support diverse electronic assembly needs across multiple industries.
Edgeboard Connectors Replacement Considerations
Consult the official EDAC 306 Series cross-reference guide for verified substitute part numbers. Do not assume interchangeability based on similar specifications alone without manufacturer confirmation.
