306-006-420-112

Edgeboard Connectors Overview

The EDAC Inc. 306-006-420-112 is a standard card edge connector receptacle featuring 12 positions with a 3.96 mm pitch. Designed for vertical panel mount installation, it utilizes gold-plated copper alloy contacts and tin termination pins. The unit accommodates a printed circuit board thickness of 1.57 mm and operates within a temperature range of -40°C to +105°C. Rated for 5 A current, the housing is constructed from thermoplastic polyester.

Edgeboard Connectors Feature Summary

• Dual-edge female contact configuration for secure card insertion
• Vertical mounting orientation with low-profile insulator body
• Gold-plated copper alloy contacts ensuring reliable conductivity

Edgeboard Connectors Applications

• Industrial control system interconnects
• Telecommunications equipment backplanes
• Automotive electronic module connections

Edgeboard Connectors Procurement Notes

Verify the specific ordering suffix against official EDAC documentation to confirm plating type and row configuration. Ensure compatibility with the target PCB thickness of 1.57 mm before procurement. Confirm that the vertical panel mount style aligns with the mechanical assembly requirements. Cross-reference the RoHS compliance status with the latest manufacturer datasheet to meet regulatory standards.

Edgeboard Connectors Selection Notes

Select this component when a dual-edge female connector with a 3.96 mm pitch is required for vertical panel applications. The 12-position count suits moderate-density signal routing needs. Verify that the 5 A current rating meets the electrical load requirements. Ensure the operating temperature range of -40°C to +105°C covers the environmental conditions of the intended deployment site.

Edgeboard Connectors Part Context

This part belongs to the EDAC 306 Series, which provides standard card edge connectors with a 3.96 mm centerline spacing. The series offers various position counts and termination options. The 306-006-420-112 specifically denotes a 12-position variant with defined plating and mounting characteristics within this standardized product line.

Edgeboard Connectors Replacement Considerations

Consult official EDAC substitution guides for direct equivalents. Verify pin count, pitch, and mounting style match exactly. Generic card edge connectors may not fit the specified 1.57 mm board thickness or panel mount constraints.
