306-006-520-102

Edgeboard Connectors Overview

The EDAC Inc. 306-006-520-102 is a standard card edge connector from the 306 series, designed for panel mounting in a vertical orientation. It features 12 positions with a 0.156-inch (3.96 mm) pitch and accepts board thicknesses of 0.054 to 0.070 inches (1.37 to 1.78 mm). The contacts are made of copper alloy with gold plating, rated for 5 A current. The housing is green thermoplastic, offering an insulation resistance of 5 Gohms.

Edgeboard Connectors Feature Summary

• Dual-edge female contact configuration for secure board insertion
• Gold-plated copper alloy contacts ensure reliable signal transmission
• Thermoplastic housing provides structural integrity and electrical isolation

Edgeboard Connectors Applications

• Industrial control systems requiring robust interconnects
• Telecommunications equipment backplanes
• Automotive electronic modules

Edgeboard Connectors Procurement Notes

Verify the specific suffix codes against the manufacturer's official ordering guide to confirm pin count, contact finish, and housing color. Ensure compatibility with the target PCB thickness range of 1.37 mm to 1.78 mm. Confirm RoHS compliance status through the latest datasheet before procurement.

Edgeboard Connectors Selection Notes

Select this component when a dual-edge, 12-position connector with a 3.96 mm pitch is required. It is suitable for applications needing vertical panel mounting and high durability. Compare against the 306 series alternatives if different board thicknesses or contact counts are necessary.

Edgeboard Connectors Part Context

This part belongs to the EDAC 306 Series, which offers various configurations for card edge applications. The series supports multiple position counts and pitch options, providing flexibility for diverse electronic assembly needs while maintaining consistent mechanical and electrical standards across the family.

Edgeboard Connectors Replacement Considerations

Cross-reference with other EDAC 306 series variants for equivalent specifications. Verify that substitute parts match the 12-position count, 3.96 mm pitch, and dual-edge female interface requirements.
