306-006-520-107

Edgeboard Connectors Overview

The EDAC Inc. 306-006-520-107 is a standard card edge connector designed for panel mount applications. It features a single row with 12 positions and a contact spacing of 3.96 mm (0.156 inches). The connector accepts printed circuit boards with a nominal thickness of 1.57 mm (0.062 inches). Electrical specifications include a current rating of 5 A and an insulation resistance of 5 GOhms. The contacts are made of copper alloy with gold plating, while the insulator body is constructed from thermoplastic polyester. The operating temperature range spans from -40 C to +105 C.

Edgeboard Connectors Feature Summary

• Accepts PCBs with a nominal thickness of 0.062 inches
• Features low profile insulator body construction
• Utilizes gold-plated copper alloy contacts for reliable connection

Edgeboard Connectors Applications

• Industrial control systems requiring robust board-to-board connections
• Communication equipment utilizing standard card edge interfaces
• Consumer electronics assemblies needing vertical panel mounting solutions

Edgeboard Connectors Procurement Notes

Verify the specific ordering suffix against the manufacturer's official documentation to ensure compatibility with required PCB thickness and termination style. Confirm that the selected variant matches the intended electrical load and environmental operating conditions. Cross-reference the part number with the latest datasheet revisions to validate material specifications and compliance status prior to procurement.

Edgeboard Connectors Selection Notes

Select this component when a single-row, vertical card edge connector is required for panels. Ensure the design accommodates the 3.96 mm pitch and 1.57 mm board thickness constraints. Verify that the thermal environment remains within the specified -40 C to +105 C range. Consider the gold contact plating for corrosion resistance in demanding environments compared to tin variants.

Edgeboard Connectors Part Context

This component belongs to the EDAC 306 series of standard card edge connectors. The series is characterized by a consistent 0.156 inch contact spacing across various position counts. The 306 series provides a standardized interface for vertical panel mounting, offering a balance of mechanical stability and electrical performance for general-purpose electronic interconnections.

Edgeboard Connectors Replacement Considerations

Direct substitutes within the same series include other position counts such as 306-010-420-107 or 306-025-520-107, provided the pin count difference is acceptable. Alternative series like 387 or 357 offer different heights or dual-edge configurations but require mechanical re-evaluation.
