306-006-521-108

Edgeboard Connectors Overview

The EDAC Inc. 306-006-521-108 is a standard card edge connector from the 306 Series, designed for vertical panel mounting applications. It features a single row of 12 positions with a contact spacing of 0.156 inches (3.96 mm). The connector utilizes gold-plated copper alloy contacts to ensure reliable signal transmission and low contact resistance. It is engineered to accept printed circuit boards with a nominal thickness of 0.062 inches (1.57 mm). The insulator body is constructed from green thermoplastic material, providing durability and electrical insulation. This component supports a current rating of 5 A and operates within a temperature range of -40°C to +105°C.

Edgeboard Connectors Feature Summary

• Accepts 0.062 inch nominal thickness PCBs
• Gold-plated copper alloy contacts for conductivity
• Vertical panel mount installation style

Edgeboard Connectors Applications

• Industrial control systems requiring robust board-to-board connections
• Telecommunications equipment utilizing standard card edge interfaces
• Test and measurement devices needing reliable high-current connections

Edgeboard Connectors Procurement Notes

Verify the specific ordering suffix against the manufacturer's official datasheet to confirm exact plating thickness, insulator color, and termination type. Ensure that the procurement documentation matches the required panel mounting configuration and contact spacing specifications before finalizing orders.

Edgeboard Connectors Selection Notes

Select this connector when a single-row, 12-position interface is required for 0.062-inch thick boards. Confirm that the application environment falls within the specified operating temperature range and that the 5 A current rating meets the system's electrical demands without exceeding thermal limits.

Edgeboard Connectors Part Context

This component belongs to the EDAC 306 Series, which offers various position counts and contact spacings. The 306-006-521-108 specifically addresses needs for compact, high-density connections in vertical orientations. It is part of a broader family of standard card edge connectors used across multiple electronic industries.

Edgeboard Connectors Replacement Considerations

Direct substitutes may include other EDAC 306 series variants with identical 12-position counts and 0.156-inch spacing, such as 306-006-521-101 or 306-006-521-112, provided they match the specific termination and mounting requirements.
