306-007-400-103

Edgeboard Connectors Overview

The EDAC Inc. 306-007-400-103 is a dual female card edge connector from the 306 series, designed for standard board applications. It features 14 positions with a 0.156-inch (3.96mm) pitch and a 0.200-inch row spacing. The connector utilizes tin-plated copper alloy contacts and a green thermoplastic polyester insulator. Rated for operation between -40°C and 105°C, it supports panel mount and through-hole termination via soldering. The unit accommodates card thicknesses of 0.054 to 0.070 inches.

Edgeboard Connectors Feature Summary

• Dual female contact configuration for standard card edge boards
• Through-hole solder termination for secure PCB attachment
• Thermoplastic polyester insulator providing thermal stability
• Tin-plated copper alloy contacts ensuring reliable conductivity

Edgeboard Connectors Applications

• Standard electronic circuit board interconnections
• Industrial control system module interfaces
• Communication equipment backplane connections
• General-purpose embedded hardware assemblies

Edgeboard Connectors Procurement Notes

Verify the specific pin count and pitch against design requirements before ordering. Confirm that the operating temperature range meets environmental specifications. Ensure the mounting style aligns with the printed circuit board layout. Check RoHS compliance status if required by project regulations. Validate mechanical dimensions for proper fit within the enclosure.

Edgeboard Connectors Selection Notes

Choose this component when a standard pitch dual female connector is needed for through-hole assembly. Consider the thermoplastic polyester material for general industrial environments. Evaluate the tin plating option against corrosion resistance needs. Compare physical dimensions with available space constraints on the target board. Assess compatibility with mating card edge thickness specifications.

Edgeboard Connectors Part Context

This part belongs to the EDAC 306 series of standard card edge connectors. The series offers various position counts and mounting options. These connectors are widely used in commercial and industrial electronics. The 306 series emphasizes reliability and ease of installation. It serves as a fundamental interconnect solution for modular designs.

Edgeboard Connectors Replacement Considerations

Consult the official EDAC 306, 316, and 356 Series Ordering Guide for verified substitutes. Cross-reference pin counts and pitch measurements strictly. Verify mechanical footprint compatibility before swapping components. Ensure electrical ratings match the original application requirements.
