306-007-400-107 is listed in the Edgeboard Connectors range at ChipApex. The manufacturer field lists EDAC Inc.. Its product description is CONN EDGE DUAL FMALE 14POS 0.156. Review the specifications below when checking this part for your BOM.
Edgeboard Connectors specifications for 306-007-400-107
- Description：CONN EDGE DUAL FMALE 14POS 0.156
- Series：306
- Mfr：EDAC Inc.
- Package：Bulk
- Card Type：Non Specified - Dual Edge
- Gender：Female
- Number of Positions/Bay/Row：7
- Number of Positions：14
- Card Thickness：0.054" ~ 0.070" (1.37mm ~ 1.78mm)
- Number of Rows：2
- Pitch：0.156" (3.96mm)
- Read Out：Dual
- Features：-
- Mounting Type：Panel Mount
- Termination：Solder Eyelet(s)
- Contact Material：Copper Alloy
- Contact Finish：Tin
- Contact Finish Thickness：-
- Contact Type：Cantilever
- Color：Green
- Flange Feature：Flush Mount, Top Opening, Threaded Insert, M3
- Operating Temperature：-40°C ~ 105°C
Edgeboard Connectors datasheet and documents for 306-007-400-107
Edgeboard Connectors Overview
The EDAC Inc. 306-007-400-107 is a standard card edge connector receptacle designed for panel mount applications. It features a single row of 14 female positions with a 3.96 mm (0.156 inch) pitch. The connector utilizes copper alloy contacts with a tin finish and is housed in green thermoplastic polyester. It supports a current rating of 5 A and operates within a temperature range of -40°C to +105°C. The unit is intended for PCBs with a thickness of 1.57 mm and employs solder pin termination.
Edgeboard Connectors Feature Summary
- Dual-edge female contact configuration for non-specified card types
- Panel mount installation with vertical orientation
- Thermoplastic polyester housing for insulation stability
Edgeboard Connectors Applications
- Industrial control systems requiring reliable board-to-board connections
- Telecommunications equipment interface modules
- Automotive electronics assembly integration
Edgeboard Connectors Procurement Notes
Verify the specific ordering suffix against official EDAC documentation to confirm contact finish, plating thickness, and housing color specifications. Ensure compatibility with target PCB thickness and mounting requirements before procurement. Confirm RoHS compliance status through the manufacturer's latest datasheet or certification documents.
Edgeboard Connectors Selection Notes
Select this component when a single-row, dual-edge female connector is required for panel-mounted applications. Verify that the 3.96 mm pitch aligns with the mating card edge design. Confirm that the 5 A current rating and operating temperature range meet the system's electrical and environmental demands.
Edgeboard Connectors Part Context
This part belongs to the EDAC 306 series of standard card edge connectors. The series offers various position counts and configurations for diverse electronic interconnection needs. The 306 series is characterized by its robust construction and suitability for high-reliability industrial environments.
Edgeboard Connectors Replacement Considerations
Consult the official EDAC 306 Series Ordering Guide for cross-reference information. Verify mechanical dimensions and electrical ratings against potential substitutes to ensure functional equivalence.
