306-007-400-108

Edgeboard Connectors Overview

The EDAC Inc. model 306-007-400-108 is a standard card edge connector receptacle designed for dual-edge board insertion. It features 14 positions with a 3.96 mm (0.156 inch) pitch. The connector utilizes tin-plated contacts and is intended for PCB thicknesses of 1.57 mm. It employs a solder pin termination method and supports vertical panel mount installation. The housing material is specified as green thermoplastic polyester, ensuring durability in industrial applications.

Edgeboard Connectors Feature Summary

• Dual-edge female connector design for secure board retention
• Vertical panel mount configuration for stable integration
• Tin-plated copper alloy contacts for reliable signal transmission
• Thermoplastic polyester housing for structural integrity

Edgeboard Connectors Applications

• Industrial control systems requiring robust interconnects
• Medical equipment needing reliable signal pathways
• Aerospace instrumentation utilizing card edge interfaces
• Computing and storage hardware backplanes

Edgeboard Connectors Procurement Notes

Verify the specific ordering suffix against the manufacturer's current datasheet to ensure compatibility with required plating options and mounting styles. Confirm that the tin-plated contact specification aligns with the application's environmental requirements. Check RoHS compliance details directly from the official documentation before procurement to meet regulatory standards.

Edgeboard Connectors Selection Notes

Select this component when a dual-edge connection with a 3.96 mm pitch is required for vertical panel mounting. Ensure the target PCB thickness matches the 1.57 mm specification for proper engagement. Consider the tin plating finish if gold plating is not necessary for the specific corrosion environment or cycle life expectations of the assembly.

Edgeboard Connectors Part Context

This part belongs to the EDAC 306 series of standard card edge connectors. The series offers various position counts and termination options. The 306-007-400-108 specifically denotes a 14-position variant with dual-edge capability. EDAC provides extensive interconnect solutions for computing, medical, and aerospace sectors, emphasizing quality assurance and global logistics support.

Edgeboard Connectors Replacement Considerations

Direct substitutes within the same series include variants with different position counts such as 306-007-421-108. Verify mechanical dimensions and electrical ratings before cross-referencing with other manufacturers' offerings to ensure functional equivalence in panel mount applications.
