306-007-520-104

Edgeboard Connectors Overview

The EDAC Inc. 306-007-520-104 is a standard card edge connector from the 306 series, designed for dual female termination. It features 14 positions with a single centerline row and a contact spacing of 0.156 inches (3.96 mm). The connector accepts printed circuit boards with a nominal thickness of 0.062 inches (1.57 mm). Constructed with copper alloy contacts finished in gold plating, it utilizes a green thermoplastic insulator body. The unit supports panel mount installation with vertical orientation and is supplied in box packaging.

Edgeboard Connectors Feature Summary

• Dual female termination configuration for reliable card edge interface
• Low profile insulator body design for compact assembly requirements
• Gold-plated copper alloy contacts ensuring stable electrical performance
• Vertical panel mount style facilitating structured board integration

Edgeboard Connectors Applications

• Industrial control system backplanes
• Telecommunications equipment interconnects
• Consumer electronics module connections
• Medical device internal circuitry interfaces

Edgeboard Connectors Procurement Notes

Verify that the specific part number matches the required 14-position count and 0.156-inch pitch before ordering. Confirm that the target application utilizes a PCB thickness of 0.062 inches to ensure proper mechanical engagement. Check regional availability as distribution channels may vary. Ensure compliance with RoHS directives if required by the end product specifications. Cross-reference the suffix codes to confirm the exact plating and housing color variants available through authorized distributors.

Edgeboard Connectors Selection Notes

Select this component when a low-profile, dual-edge female connector is needed for 14-position applications. The 0.156-inch spacing suits standard board layouts requiring moderate density. Consider the vertical panel mount style for fixed installations rather than flexible cabling needs. Evaluate the thermoplastic housing material for environmental resistance appropriate to the operating conditions. Compare against other 306 series variants if different position counts or spacing options are required for the design.

Edgeboard Connectors Part Context

This connector belongs to the EDAC 306 series of card edge connectors, which are engineered for general-purpose electronic interconnections. The series offers various position counts and mounting styles to accommodate diverse board designs. As a standard header type, it provides a robust connection between the edge card and the main system board. The product line emphasizes reliability and ease of assembly for manufacturing environments.

Edgeboard Connectors Replacement Considerations

Compatible substitutes within the same series include variations such as 306-007-500-104 or 306-007-520-178, provided the pin count and spacing remain identical. Verify that any replacement maintains the dual female gender and vertical panel mount orientation. Ensure the substitute part retains the 0.156-inch contact spacing to fit existing PCB footprints without redesign.
