306-007-521-112

Edgeboard Connectors Overview

The EDAC Inc. 306-007-521-112 is a standard card edge connector designed for panel mount applications. It features a dual female configuration with 14 positions arranged in a single row. The component utilizes a 0.156-inch (3.96mm) contact spacing and accepts printed circuit boards with a nominal thickness of 0.062 inches (1.57mm). Contacts are constructed from copper alloy and feature gold plating to ensure reliable signal transmission. The insulator body is green thermoplastic, supporting an operating temperature range of -40°C to +105°C.

Edgeboard Connectors Feature Summary

• Dual female contact configuration for secure board retention
• Gold-plated copper alloy contacts for corrosion resistance
• Low profile thermoplastic insulator body construction
• Vertical panel mount installation style

Edgeboard Connectors Applications

• Industrial control system interconnects
• Telecommunications equipment backplanes
• Test and measurement instrument modules
• General-purpose electronic circuit board connections

Edgeboard Connectors Procurement Notes

Verify the specific ordering suffix against official EDAC documentation to confirm exact pin count, plating thickness, and mounting hardware requirements. Ensure compatibility with target PCB thickness specifications before procurement. Confirm that the selected variant meets all necessary environmental and electrical ratings for the intended application environment.

Edgeboard Connectors Selection Notes

Select this connector when a single-row, dual-edge female interface is required for vertical panel mounting. The 3.96mm pitch accommodates standard board widths while providing robust mechanical stability. Consider the gold plating for environments requiring high reliability and low contact resistance over extended operational lifecycles.

Edgeboard Connectors Part Context

This component belongs to the EDAC 306 Series, which specializes in standard card edge connectors. The series is characterized by its .156 inch contact spacing and versatile mounting options. These connectors are engineered for durability and consistent performance in demanding electronic assemblies, serving as critical interface points between circuit boards and chassis systems.

Edgeboard Connectors Replacement Considerations

Cross-reference with other EDAC 306 series variants such as 306-007-521-107 or 306-007-521-112 equivalents if different termination styles or plating options are needed. Verify dimensional compatibility with existing PCB layouts and panel cutouts before substituting.
