306-008-421-101

Edgeboard Connectors Overview

The EDAC Inc. 306-008-421-101 is a standard card edge connector receptacle featuring 16 positions with a 3.96 mm (0.156 inch) pitch. Designed for dual-edge PCBs, it utilizes a vertical panel mount style with solder pin termination. The contacts are constructed from copper alloy and finished with tin plating to ensure reliable signal transmission. The housing is made of green thermoplastic polyester, supporting a board thickness range of 1.37 mm to 1.78 mm. This component operates within a temperature range of -40°C to +105°C and complies with RoHS3 standards.

Edgeboard Connectors Feature Summary

• Dual-edge female contact configuration for secure connection to double-sided circuit boards
• Vertical panel mount design with flat flange and top opening for straightforward installation
• Solder pin termination method ensures stable mechanical and electrical attachment to the PCB
• Thermoplastic polyester insulation provides durability and resistance in industrial environments

Edgeboard Connectors Applications

• Industrial control systems requiring robust card edge interfaces
• Telecommunications equipment utilizing modular board architectures
• Test and measurement instruments needing reliable signal interconnects
• Automotive electronics assemblies demanding high-temperature stability

Edgeboard Connectors Procurement Notes

Verify the specific ordering suffix against the manufacturer's official datasheet to confirm contact plating, flange characteristics, and mounting orientation. Ensure the selected variant matches the required PCB thickness and pitch specifications for your application. Cross-reference the part number with authorized distributors to confirm current availability and compliance status before finalizing procurement orders.

Edgeboard Connectors Selection Notes

Select this connector when a dual-edge female interface with a 3.96 mm pitch is required for vertical panel mounting. Consider the tin-plated contacts for general-purpose applications where gold plating is not strictly necessary. Evaluate the thermoplastic polyester housing for environmental resistance and verify that the operating temperature range meets the system's thermal requirements.

Edgeboard Connectors Part Context

This component belongs to the EDAC 306 series of standard card edge connectors, which are widely used in various electronic industries. The series offers multiple position counts and pitch options to accommodate different board designs. As a receptacle type, it pairs with corresponding card edge plugs or directly interfaces with double-sided PCBs to establish electrical connections.

Edgeboard Connectors Replacement Considerations

Direct substitutes include other EDAC 306 series variants with matching 16-position count and 3.96 mm pitch. Verify compatibility regarding flange dimensions, mounting style, and contact material before replacing. Consult the manufacturer's cross-reference guide for approved alternative part numbers.
