306-008-520-112

Edgeboard Connectors Overview

The EDAC Inc. 306-008-520-112 is a standard card edge connector receptacle featuring 16 positions arranged in a dual-edge configuration. It utilizes a 3.96 mm (0.156 inch) contact spacing and is designed for PCBs with a nominal thickness of 1.57 mm. The component employs through-hole solder termination with gold-plated copper alloy contacts, ensuring reliable electrical performance. Rated for 5 A current at an insulation resistance of 5 GOhms, it operates within a temperature range of -40°C to +105°C. The housing is constructed from green thermoplastic polyester.

Edgeboard Connectors Feature Summary

• Dual-edge female connector design accommodates non-specified board types.
• Gold-plated copper alloy contacts provide corrosion resistance and conductivity.
• Flush-mount panel installation style ensures secure mechanical stability.

Edgeboard Connectors Applications

• Industrial control system interconnections
• Communication equipment backplanes
• Consumer electronic module interfaces

Edgeboard Connectors Procurement Notes

Verify the specific ordering suffix against the manufacturer datasheet to confirm pin count, spacing, and plating specifications. Ensure compatibility with the target PCB thickness of 1.57 mm. Confirm RoHS compliance status and lead times directly with authorized distributors prior to purchase.

Edgeboard Connectors Selection Notes

Select this component when a low-profile, dual-edge receptacle with 3.96 mm spacing is required. It is suitable for applications demanding high insulation resistance and operation up to 105°C. Consider the flush-mount requirement and through-hole termination method during PCB layout design.

Edgeboard Connectors Part Context

This part belongs to the EDAC 306 series of standard card edge connectors. The series offers various position counts and mounting styles, providing versatile solutions for board-to-board or board-to-panel connections in compact electronic assemblies.

Edgeboard Connectors Replacement Considerations

Cross-reference compatible parts such as the 306-008-521-102 for similar specifications. Verify that substitute components match the 16-position count, 3.96 mm pitch, and dual-edge interface requirements before implementation.

Edgeboard Connectors FAQ

What is the maximum operating temperature for this connector?

The maximum operating temperature is +105°C.

Does this connector support single-sided or double-sided cards?

It is designed as a dual-edge connector, accepting non-specified card types.
