306-009-400-107

Edgeboard Connectors Overview

The EDAC Inc. model 306-009-400-107 is a standard card edge connector receptacle designed for vertical panel mount applications. It features 18 positions with a 3.96 mm pitch and supports a board thickness of 1.57 mm. The contacts are constructed from copper alloy with tin plating, rated for 5 A current. The housing utilizes green thermoplastic polyester insulation, providing an insulating resistance of 5 GOhms. Operating temperatures range from -40 C to +105 C.

Edgeboard Connectors Feature Summary

• Vertical panel mount configuration for secure installation
• Single row contact arrangement with dual edge compatibility
• Thermoplastic polyester housing for structural stability

Edgeboard Connectors Applications

• Industrial control systems requiring reliable signal transmission
• Telecommunications equipment interface connections
• Automotive electronic module interconnections

Edgeboard Connectors Procurement Notes

Verify the specific contact plating finish against project requirements, as datasheet sources indicate variations between tin and gold finishes for this series. Confirm that the 1.57 mm board thickness specification aligns with the target PCB design. Ensure the vertical orientation matches the mechanical constraints of the enclosure. Cross-reference the manufacturer part number directly with official EDAC documentation to confirm availability and exact material specifications before finalizing procurement decisions.

Edgeboard Connectors Selection Notes

Select this component when a single-row, 18-position connection is required for dual-edge card insertion. The 3.96 mm pitch accommodates standard board widths while maintaining compact spacing. Verify that the operating temperature range meets environmental conditions. Consider the thermoplastic polyester housing durability for long-term mechanical stability in fixed installations.

Edgeboard Connectors Part Context

This component belongs to the EDAC 306 series of standard card edge connectors. The series offers various position counts and mounting styles. The 306-009-400-107 specifically provides a female receptacle solution for mating with edge-plated circuit boards. It serves as a critical interface point in modular electronic architectures requiring robust physical and electrical connectivity.

Edgeboard Connectors Replacement Considerations

Compatible substitutes within the same series include models with identical pitch and position counts but different plating or housing colors. Verify mechanical dimensions and electrical ratings match exactly before substitution.
