306-009-421-101

Edgeboard Connectors Overview

The EDAC Inc. 306-009-421-101 is a standard card edge connector receptacle featuring 18 positions arranged in a dual-edge configuration. It utilizes a 3.96 mm (0.156 inch) pitch with gold-plated copper alloy contacts rated for 5 A current. Designed for panel mount installation at a vertical angle, it accepts board thicknesses between 1.37 mm and 1.78 mm. The housing is constructed from thermoplastic polyester, offering an operating temperature range of -40°C to 105°C.

Edgeboard Connectors Feature Summary

• Dual-edge female contact configuration for secure board insertion
• Gold-plated copper alloy contacts ensure reliable signal transmission
• Thermoplastic polyester insulation provides thermal stability
• Vertical panel mount design facilitates structured integration

Edgeboard Connectors Applications

• Industrial control system interconnections
• Telecommunications equipment backplanes
• Test and measurement instrument interfaces
• Automotive electronic module connections

Edgeboard Connectors Procurement Notes

Verify the specific suffix codes against official EDAC documentation to confirm exact pin counts and termination styles. Ensure compatibility with target PCB thickness specifications before procurement. Confirm RoHS compliance status through manufacturer datasheets. Validate that the dual-edge requirement matches the application's mechanical constraints. Cross-reference ordering guides for accurate part identification.

Edgeboard Connectors Selection Notes

Select this component when a dual-edge connection with a 3.96 mm pitch is required. Verify that the 18-position count aligns with circuit requirements. Ensure the vertical panel mount style fits the enclosure design. Confirm that the 5 A current rating meets electrical load demands. Check that the operating temperature range suits the environmental conditions.

Edgeboard Connectors Part Context

This component belongs to the EDAC 306 series, which specializes in standard card edge connectors. The series offers various position counts and mounting options. These connectors are designed for robust industrial applications requiring reliable high-current connections. The 306 series emphasizes durability and precise alignment for dual-edge boards.

Edgeboard Connectors Replacement Considerations

Consult the EDAC 306 Series Ordering Guide for direct substitutes. Verify identical pitch, position count, and termination methods. Ensure replacement parts match the dual-edge specification and panel mount requirements.
