306-009-500-103

$8.29

Description：CONN EDGE DUAL FMALE 18POS 0.156
Series：306
Mfr：EDAC Inc.
Package：Bulk

SKU:a894d9a75821 Category: Edgeboard Connectors Brand: EDAC Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

306-009-500-103 is listed in the Edgeboard Connectors range at ChipApex. The manufacturer field lists EDAC Inc.. Its product description is CONN EDGE DUAL FMALE 18POS 0.156. Review the specifications below when checking this part for your BOM.

Edgeboard Connectors specifications for 306-009-500-103

Description：CONN EDGE DUAL FMALE 18POS 0.156
Series：306
Mfr：EDAC Inc.
Package：Bulk
Card Type：Non Specified - Dual Edge
Gender：Female
Number of Positions/Bay/Row：9
Number of Positions：18
Card Thickness：0.054" ~ 0.070" (1.37mm ~ 1.78mm)
Number of Rows：2
Pitch：0.156" (3.96mm)
Read Out：Dual
Features：-
Mounting Type：Panel Mount
Termination：Solder Eyelet(s)
Contact Material：Copper Alloy
Contact Finish：Gold
Contact Finish Thickness：10.0µin (0.25µm)
Contact Type：Cantilever
Color：Green
Flange Feature：Flush Mount, Floating Bobbin, 0.116" (2.95mm) Dia
Operating Temperature：-40°C ~ 105°C

Edgeboard Connectors datasheet and documents for 306-009-500-103

306-009-500-103

Edgeboard Connectors Overview

The EDAC Inc. model 306-009-500-103 is a standard card edge connector header designed for reliable signal transmission in electronic assemblies. This component features a single centerline row with 9 positions and a contact spacing of 3.96 mm. It is engineered to accept printed circuit boards with a nominal thickness of 1.57 mm. The unit utilizes gold-plated copper alloy contacts housed within a thermoplastic polyester insulator body. Rated for 5 A current, it operates effectively within a temperature range of -40°C to +105°C. The design ensures stable mechanical engagement with card edge interfaces.

Edgeboard Connectors Feature Summary

Single centerline row configuration providing compact vertical mounting solutions
Gold-plated copper alloy contacts ensure durable electrical connectivity
Thermoplastic polyester insulator body supports high-temperature operational environments

Edgeboard Connectors Applications

Industrial control system interconnections
Communication equipment board-to-board linking
Consumer electronics assembly integration

Edgeboard Connectors Procurement Notes

Verify the specific manufacturer part number against official EDAC documentation to confirm compatibility. Ensure that the ordering suffix matches the required contact plating and housing material specifications. Cross-reference technical drawings for dimensional accuracy before procurement to prevent installation errors in final assemblies.

Edgeboard Connectors Selection Notes

Select this component when a single-row header with 3.96 mm pitch is required for PCBs of 1.57 mm thickness. Consider the 5 A current rating and 105°C maximum operating temperature for suitability in moderate thermal environments. Verify that the vertical panel mount style aligns with the mechanical constraints of the target enclosure design.

Edgeboard Connectors Part Context

This connector belongs to the EDAC 306 series of standard card edge connectors. The series offers various position counts and row configurations to support diverse electronic interface needs. Components in this family are characterized by robust construction and consistent performance across industrial and commercial applications requiring secure card edge connections.
