306-009-500-107

Edgeboard Connectors Overview

The EDAC Inc. 306-009-500-107 is a standard card edge connector designed for single-row applications. It features 18 positions with a contact spacing of 0.156 inches (3.96 mm). The component utilizes copper alloy contacts plated with gold and is housed in a green thermoplastic insulator body. Rated for 5 A current, it supports printed circuit boards with a nominal thickness of 0.062 inches (1.57 mm). The connector operates within a temperature range of -40°C to +105°C and offers an insulation resistance of 5 GOhms.

Edgeboard Connectors Feature Summary

• Accepts PCBs with a nominal thickness of 0.062 inches
• Features a low-profile insulator body design
• Utilizes gold-plated copper alloy contacts for reliable conductivity

Edgeboard Connectors Applications

• Panel mount interconnect systems
• Single-sided edgeboard connections
• Industrial control modules requiring robust signal transmission

Edgeboard Connectors Procurement Notes

Verify the specific ordering suffix against the manufacturer's official documentation to ensure compatibility with required mounting styles and termination types. Confirm that the selected variant matches the intended board thickness and row configuration. Cross-reference the part number with the latest datasheet to validate environmental ratings and material specifications before finalizing procurement orders.

Edgeboard Connectors Selection Notes

Select this connector when a single-row interface with a 3.96 mm pitch is required for panel-mounted applications. Ensure the host PCB adheres to the specified 1.57 mm thickness tolerance for proper engagement. Consider the operating temperature range and current rating to verify suitability for the target electrical environment and mechanical constraints.

Edgeboard Connectors Part Context

This component belongs to the EDAC 306 series of standard card edge connectors. The series is characterized by its versatility in handling various board thicknesses and its focus on durable, high-reliability connections for industrial and commercial electronics. The 306 series typically includes both single and dual-row configurations to accommodate different density requirements.

Edgeboard Connectors Replacement Considerations

Direct substitutes include other EDAC 306 series variants with matching position counts and pitch dimensions. Verify that any alternative part maintains the same 0.156 inch spacing and compatible PCB thickness specifications to ensure mechanical fit and electrical performance equivalence.
